Alimentatore PC Thermaltake Munich 430
Alimentatore PC Thermaltake Munich 430 430W 80+ ATX
ID: 802
MODELLO: W0391RE
NOME COMMERCIALE: Thermaltake Munich 430W
CONDIZIONE: Nuovo
RECESSO: Fino a 14 giorni (politica di recesso )
Visualizzazioni 926
Recensioni 0
Rating 0 di 5
TAG
DESCRIZIONE
ATX 12V V2.3 enables most reliable and robust power delivery.
Stable 430W continuous output (peak power 500W) @ 40 ℃ operating environment.
Robust and dedicated single +12V output provides superior performance under all types of system loading.
80 PLUS® Certified: with 80-86% efficiency @ 20-100% load under real world load conditions.
Double-forward switching circuitry offers low power loss and high reliability.
Universal AC input 100V~240V automatically scans and detects the correct voltage.
Active Power Factor Correction provides clean and reliable power to your system.
Ultra-silent operation with intelligent 12cm cooling fan speed control.
Intel & AMD CPU compliant.
Nvidia & ATI/AMD graphic card compatible.
Dimension: 150mm(W)x86mm(H)x140mm(L).
High reliability: MTBF>100,000 hours.
Built in industrial-grade protections: Over Current, Over Voltage, Over Power and Short-Circuit protections.
Safety / EMI : TUV, CE, UL, FCC, BSMI.
New Thermaltake SMART 430W saves energy through its high energy efficiency of up to 80% and is 80 PLUS certified
Supports Energy Star 5.0* energy standard:
New Thermaltake SMART 430W is suitable for use in Energy Star-compatible computers.
Supports Intel Deep Power Down C6 Status:
New Thermaltake SMART 430W helps your PC system operate more power efficiently.
Corresponds to the EU directives on WEEE and RoHS:
Thermaltake considers its full impact on the environment during manufacturing and maintains green facilities to ensure New Thermaltake SMART 430W meets WEEE & RoHS requirements.
| P/N | W0391RE |
| Type | Intel ATX 12V 2.3 |
| Max. Output Capacity | 430W |
| Peak Output Capacity | 500W |
| Color | Black |
| Dimension of main body（H x W x D） | 86mm x 150mm x 140mm |
| PFC （Power Factor Correction） | Active PFC |
| Power Good Signal | 100-500 msec |
| Hold Up Time | 16msec (minimum) @ 65% load at 230Vac 50Hz input. |
| Input current | 8A – 5A |
| Input Frequency Range | 50 Hz - 60 Hz |
| Input Voltage | 100 Vac- 240 Vac |
| Operating Temperature | +10℃ to +40℃ |
| Operating Humidity | 20% to 85%,non-condensing |
| Storage Temperature | -40 ℃ to +70 ℃ |
| Storage Humidity | 5% to 95%, non-condensing |
| Cooling System | 120mm Fan: 2000 R.P.M. ± 10% |
| Efficiency | 80% efficiency @ 20-100% load |
| MTBF | 100,000 hrs minimum |
| Safety Approval | TUV, CE |
| PCI-E adaptor cable | x 1 |
