Processor

Supports 8th Generation Intel^® Core™ Processors, and Intel^® Pentium^® and Celeron^® Processors for Socket LGA1151

See supported processors

Chipset

Intel^® Z370 Chipset

Memory

• 4 x DDR4 memory slots, support up to 64GB
  • Supports DDR4 4000+(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) /2800(OC)/ 2667/ 2400/ 2133 MHz¹
• Supports Dual-Channel mode
• Supports non-ECC, un-buffered memory
• Supports Intel^® Extreme Memory Profile (XMP)

1. Please refer to the Compatibility for more information on compatible memory

Slots

• 3 x PCIe 3.0 x16 slots (support x16/x0/x4, x8/x8/x4 modes)
• 3 x PCIe 3.0 x1 slots

Onboard Graphics

• 1 x HDMI^™ port, supports a maximum resolution of 4096x2160@30Hz, 2560x1600@60Hz
• 1 x DisplayPort port, supports a maximum resolution of 4096X2304@24Hz, 3840X2160@60Hz,1920X1200@60Hz

Multi-GPU

• Supports 2-Way NVIDIA^® SLI™ Technology
• Supports 3-Way AMD CrossFire™ Technology

Storage

Intel^® Z370 Chipset

• 6 x SATA 6Gb/s ports¹
• 2 x M.2 slots (Key M)
  • Support up to PCIe 3.0 x4 and SATA 6Gb/s
  • Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host Card²
  • M2_1 slot supports 2242/ 2260 /2280/ 22110 storage devices
  • M2_2 slot supports 2242/ 2260 /2280 storage devices
  • Intel^® Optane™ Memory Ready for all M.2 slots³

1. M.2 and SATA ports maximum support 1x M.2 PCIe SSD + 1x M.2 SATA SSD + 5x SATA HDDs.
2. The Turbo U.2 Host Card is not included, please purchase separately.
3. Before using Intel^® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

RAID

Intel^® Z370 Chipset

• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
• Supports RAID 0, RAID 1 for M.2 PCIe storage devices¹

1. M.2 PCIe RAID volume can be created with M.2 GENIE.

USB

Audio

Realtek^® ALC1220 Codec

• 7.1-Channel High Definition Audio
• Supports S/PDIF output

LAN

• 1 x Intel I219-V Gigabit LAN controller

Wirsless LAN & Bluetooth^®

Intel^® Dual Band Wireless-AC 8265 card

• Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 867 Mbps speed.
• Supports Dual Mode Bluetooth^® 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2

Internal connectors

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 6 x SATA 6Gb/s connectors
• 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
• 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 1 x 4-pin CPU fan connector
• 1 x 4-pin water pump fan connector
• 4 x 4-pin system fan connectors
• 1 x Front panel audio connector
• 2 x Front panel connectors
• 2 x 5050 RGB LED strip 12V connectors
• 1 x WS2812B Individually Addressable RGB LED strip 5V connector
• 1 x CORSAIR Individually Addressable RGB LED strip 5V connector
• 1 x TPM module connector
• 1 x Chassis Intrusion connector
• 1 x Clear CMOS jumper

Back panel ports

Dimensions

• 12 in. x 9.6 in. (30.4 cm x 24.3 cm)
• ATX Form Factor

Mounting

9 mounting holes
