DESCRIZIONE

• CPU
  AMD Socket AM1 Athlon™/Sempron™ Processors
  Supports CPU up to 4 cores
  * Refer to www.asus.com for CPU support list
• Chipset
  Build in AMD Sempron & Athlon-Series APUs
• Memoria
  2 x DIMM, Max. 32GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory
  Single Channel Memory Architecture
  Support AMD Memory Profile (AMP) memory
  * The Max. 32GB memory capacity can be supported with DIMMs of 16GB (or above). ASUS will update QVL once the DIMMs are available on the market.
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows® OS when you want to install 4GB or more memory on the motherboard.
• Grafica
  Integrated AMD Radeon™ R Series Graphics in the APU
  Multi-VGA output support : HDMI/DVI-D/RGB ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 1920 x 1080 @ 60 Hz*¹
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  - Supports RGB with max. resolution 2048 x 1536 @ 60 Hz
  Maximum shared memory of 2048 MB
• Slot di Espansione
  1 x PCIe 2.0 x4
• Storage
  AMD® Sempron & Athlon-Series APUs :
  2 x SATA 6Gb/s port(s), yellow
• LAN
  Realtek® 8111GR, 1 x Gigabit LAN Controller(s)
• Audio
  Realtek® ALC887-VD 8-Channel High Definition Audio CODEC *²
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
• Porte USB
  AMD® Sempron & Athlon-Series APUs :
  2 x USB 3.0/2.0 port(s) (2 at back panel, blue)
  AMD® Sempron & Athlon-Series APUs :
  8 x USB 2.0/1.1 port(s) (4 at back panel, black, 4 at mid-board)
• Caratteristiche Speciali
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  - Anti-Surge
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  - Network iControl
  - USB 3.0 Boost
  ASUS Quiet Thermal Solution :
  - ASUS Fan Xpert
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 2
  - ASUS MyLogo 2
• Operating System Support
  Windows® 8.1 32bit/64bit
  Windows® 8 32bit/64bit
  Windows® 7 32bit/64bit
  Windows® XP 32bit
• Porte I/O Posteriori
  1 x PS/2 keyboard (purple)
  1 x PS/2 mouse (green)
  1 x DVI-D
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  2 x USB 3.0 (blue)
  4 x USB 2.0
  1 x COM port(s)
  3 x Audio jack(s)
• I/O Interne
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x TPM header
  1 x LPT header
  1 x COM port(s) connector(s)
  2 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s)
  1 x Chassis Fan connector(s)
  1 x 24-pin EATX Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x Internal speaker connector(s)
  1 x System panel(s)
• Accessori
  User's manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
• BIOS
  64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information
• Disco di Supporto
  Drivers
  ASUS utilities
  ASUS Update
  Anti-virus software (OEM version)
• Dimensioni Scheda
  Mini ITX Form Factor
  6.7 inch x 6.7 inch ( 17 cm x 17 cm )
• Note
  *1: Please check the specifications of your AMD APU for capabilities. Video playback at 4096 x 2160 pixels may not be guaranteed.
  *2: Use a chassis with HD audio module in the front panel to support an 8-channel audio output.
