DESCRIZIONE

• CPU
  Intel® Socket 1151 for 7^th Generation for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  * Refer to www.asus.com for CPU support list
• Chipset
  Intel® Z270
• Memoria
  4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3733(O.C.)/3600(O.C.)/3500(O.C.)/3466(O.C.)/3400(O.C.)/2666(O.C.)/2400(O.C.) MHz Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• Grafica
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DisplayPort 1.2 ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
  - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
  Maximum shared memory of 1024 MB
• Supporto Multi-GPU
  Supports NVIDIA® 2-Way SLI™ Technology
  Supports AMD 3-Way CrossFireX™ Technology
• Slot di Espansione
  2 x PCIe 3.0/2.0 x16 (Single at x16, dual at x8/x8)
  1 x PCIe 3.0/2.0 x16
  1 x PCIe 3.0 x4 *¹
• Storage
  Intel® Z270 Chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)
  1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)*²
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology*³
  Intel® Rapid Storage Technology supports*³
  Intel® Optane™ Memory Ready *⁴
• LAN
  Intel® I219V
  Anti-surge LANGuard
  ROG GameFirst IV
• Wireless Data Network
  Wi-Fi 802.11 a/b/g/n/ac
  Supports MU-MIMO
• Bluetooth
  Bluetooth V4.1*⁵
• Audio
  ROG SupremeFX 8-Channel High Definition Audio CODEC S1220
  - Impedance sense for front and rear headphone outputs
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - High quality 113 dB SNR stereo playback output and 110 dB SNR recording input
  - SupremeFX Shielding Technology
  - ESS® ES9023P
  - Supports up to 32-Bit/192kHz playback *⁶
  Audio Feature :
  - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
  - Sonic Radar III
  - Sonic Studio III
• Porte USB
  ASMedia® USB 3.1 Gen 2 controller :
  1 x USB 3.1 Gen 2 front panel connector port(s)
  Intel® USB 3.1 controller :
  2 x USB 3.1 port(s) (2 at back panel, )
  Intel® Z270 Chipset :
  6 x USB port(s) (4 at back panel, )
  ASMedia® USB 3.1 Gen 1 controller :
  2 x USB port(s) (2 at back panel, )
  Intel® Z270 Chipset : *⁷
  4 x USB 2.0 port(s)
• Caratteristiche Overclock
  Clear CMOS button
  ROG RAMCache II
  ROG CPU-Z
  ROG CloneDrive
  Pre-mounted I/O Shield
  MemOK! Button
  Slow Mode
  ReTry Button
  Safe Boot Button
  Start Button
  Reset Button
  LN2 Mode
  GameFirst IV
  ROG Aura
  - Aura Lighting Control
  - Aura RGB Strip Headers
  Extreme Engine Digi+ :
  - MicroFine Alloy Chokes
  - NexFET™ Power Block MOSFET
  - 10K Black Metallic Capacitors
  Mem TweakIt
  KeyBot II
  - X.M.P.
  - ClrCMOS
  - Power On
  UEFI BIOS features :
  - O.C. Profile
  - Tweakers' Paradise
  - ROG SSD Secure Erase
  - Graphic Card Information Preview
  ROG RAMDisk
  Extreme Tweaker
  USB BIOS Flashback
• Caratteristiche Speciali
  ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
  - 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App
  SafeDIMM slot
  ASUS Exclusive Features :
  - MemOK!
  - AI Suite 3
  - Ai Charger
  ASUS Q-Design :
  - ASUS Q-Code
  - ASUS Q-LED ()
  - ASUS Q-DIMM
  - ASUS Q-Connector
  Gaming Aesthetics :
  - 3D printing friendly
  Overclocking Protection :
  - ASUS C.P.R.(CPU Parameter Recall)
• Porte I/O Posteriori
  1 x DisplayPort
  1 x HDMI
  1 x LAN (RJ45) port(s)
  2 x USB 3.1 Gen 2 ()Type-A + USB Type-C^TM
  6 x USB 3.1 Gen 1 (blue)
  1 x Optical S/PDIF out
  1 x Clear CMOS button(s)
  1 x USB BIOS Flashback Button(s)
  5 x LED-illuminated audio jacks
• I/O Interne
  1 x AAFP connector
  2 x Aura RGB Strip Headers
  1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x TPM connector(s)
  8 x SATA 6Gb/s connector(s)
  2 x Chassis Fan connector(s)
  2 x W_PUMP+ connector
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x 4-pin EZ_PLUG Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s) (Q-Connector)
  1 x Slow Mode switch(es)
  1 x Thermal sensor connector(s)
  1 x EZ Plug connector(s) (4-pin Molex power connector)
  1 x Power-on button(s)
  1 x Reset button(s)
  1 x BIOS Switch button(s)
  1 x Clear CMOS button(s)
  1 x 5-pin EXT_FAN(Extension Fan) connector
  1 x USB BIOS Flashback button(s)
  1 x LN2 Mode jumper(s)
  1 x ROG extension (ROG_EXT) header(s)
  1 x Safe Boot button
  1 x ReTry button
  1 x T_Sensor Connector
  2 x W_Pump+ Header
  1 x EXT_Fan header
  1 x W_IN header
  1 x W_OUT header
  1 x W_FLOW header
  1 x USB 3.1 Gen 2 front panel connector
  1 x MemOK! Button
  1 x RSVD Switch
  1 x 9 pin Monoblock sensor
  8 x Radiator Fan Headers
• Accessori
  User's manual
  8 x SATA 6Gb/s cable(s)
  1 x M.2 Screw Package
  1 x CPU installation tool
  1 x Fan Extension Card (3 x 4-pin fan out)
  1 x Fan Extension card screw pack
  1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n compliant)
  1 x SLI HB BRIDGE(2-WAY-M)
  1 x ROG big sticker
  1 x Q-Connector
  1 x 10-in-1 ROG cable label
  2 x Thermal sensor cable pack(s)
  1 x Extension Cable for RGB strips (80 cm)
  1 x USB drive with utilities and drivers
  1 x ROG coaster(s)
  1 x ROG Monoblock
  1 x ROG Monoblock Accessory pack
  1 x M.2 Heatsink package
• BIOS
  2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, F9 Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Sistema Operativo
  Windows® 10 64-bit
  Windows® 8.1 64-bit *⁸
  Windows® 7 32-bit *⁸
  Windows® 7 64-bit *⁸
• Dimensioni Scheda
  Extended ATX Form Factor
  12 inch x 10.7 inch ( 30.5 cm x 27.2 cm )
