DESCRIZIONE

• CPU
  Intel® Socket 2011-v3 Core™ i7 Processors
  Supports Intel® 22 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  * Refer to www.asus.com for CPU support list
• Chipset
  Intel® X99
• Memory
  8 x DIMM, Max. 64GB, DDR4 3300(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory
  Quad Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• Multi-GPU Support
  Supports NVIDIA® 4-Way SLI™ Technology *¹
  Supports NVIDIA® 3-Way SLI™ Technology
  Supports NVIDIA® SLI™ Technology
  Supports AMD 4-Way CrossFireX Technology
  Supports AMD 3-Way CrossFireX™ Technology
  Supports AMD CrossFireX™ Technology
• Expansion Slots
  4 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x8/x8 or x16/x8/x8/x8 mode with 40-LANE CPU; x16, x16/x8, x8/x8/x8 mode with 28-LANE CPU) *²
  1 x PCIe 2.0 x16 (x4 mode) *³
  1 x PCIe 2.0 x1 *³
• Storage
  New Intel® Core™ i7 Processors :
  1 x M.2 Socket 3, , with M Key, type 2260/2280/22110 storage devices support ( Supports PCIE SSDs only)
  Intel® X99 chipset :
  1 x SATA Express port, red, compatible with 2 x SATA 6.0 Gb/s ports
  8 x SATA 6Gb/s port(s), red, *⁴,
  Supports Intel® Smart Response Technology, Intel® Rapid Recovery Technology*⁵
  ASMedia® SATA Express controller : *⁶
  1 x SATA Express port, red, compatible with 2 x SATA 6.0 Gb/s ports
• LAN
  Intel® I218V, 1 x Gigabit LAN Controller(s), featuring GAMEFIRST III
  Intel® LAN- Dual interconnect between the Integrated LAN controller and Physical Layer (PHY)
  Anti-surge LANGuard
• Wireless Data Network
  Wi-Fi 802.11a/b/g/n/ac
  Supports dual band frequency 2.4/5 GHz
  Up to 1300Mbps transfer speed
• Bluetooth
  Bluetooth V4.0
• Audio
  ROG SupremeFX 8-Channel High Definition Audio CODEC
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - SupremeFX Shielding Technology
  - ELNA® premium audio capacitors
  Audio Feature :
  - Blu-ray audio layer Content Protection
  - DTS Connect
  - Optical S/PDIF out port(s) at back panel
  - Sonic SoundStage
  - Sonic SenseAmp
  - Sonic Studio
  - Sonic Radar II
• USB Ports
  Intel® X99 chipset :
  4 x USB 3.1 Gen 1 port(s) (4 at mid-board)
  Intel® X99 chipset : *⁷
  6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)
  ASMedia® USB 3.0 controller : *⁸
  10 x USB 3.1 Gen 1 port(s) (10 at back panel, blue)
• OC Panel
  2.6 " LCM display
  EXTREME/NORMAL mode switch
  EXTREME Mode for subzero OC benching:*⁹
  - VGA Hotwire
  - Subzero Sense
  - Slow Mode
  - Pause Switch
  - VGA SMB header
  - ProbeIt
  - 4 x 4-pin extra fan connectors
  NORMAL Mode for in-chassis usage:*¹⁰
  - CPU Level Up OC button
  - FanSpeed control button
  - LCM backlight on/off button
  I/O Ports:
  - POWER：1 x SATA power connector
  - ROG_EXT port：1 x 18-1 pin data connection port
• Overclocking Features
  DirectCU thermal design
  ROG Connect :
  - RC Diagram
  - RC Remote
  - RC Poster
  Extreme Engine Digi+ IV :
  - IR3555 PoweIRstage®
  - MicroFine Alloy Chokes
  - 10K Black Metallic Capacitors
  ROG Extreme OC kit :
  - ReTry button
  - Safe Boot button
  - Start button
  - Reset button
  - Slow Mode
  - LN2 Mode
  - PCIe x16 Lane Switch
  - Debug LED
  ProbeIt
  KeyBot
  - CPU Level Up
  - XMP
  - Direct Key
  UEFI BIOS features :
  - ROG BIOS Print
  - GPU.DIMM Post
  - Tweakers' Paradise
  - ROG SSD Secure Erase
  - Graphic Card Information Preview
  ROG RAMDisk
  GameFirst III
  iROG
  Extreme Tweaker
  USB BIOS Flashback
  Overclocking Protection :
  - COP EX (Component Overheat Protection - EX)
  - Voltiminder LED II
• Special Features
  ASUS Exclusive Features :
  - MemOK!
  - AI Suite 3
  - Ai Charger+
  - USB Charger+
  - USB 3.1 Boost
  - Disk Unlocker
• Operating System Support
  Windows® 8.1
  Windows® 8
  Windows® 7
• Back I/O Ports
  1 x PS/2 keyboard/mouse combo port(s)
  1 x LAN (RJ45) port(s)
  10 x USB 3.1 Gen 1 (blue)
  2 x USB 2.0 (one port can be switched to ROG Connect)
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x Clear CMOS button(s)
  1 x ROG Connect On/ Off switch(es)
  1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.0
• Internal I/O
  2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  2 x SATA Express connector: red, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)
  1 x M.2 Socket 3 for M Key, type 2260/2280/22110 storage devices support ( Support PCIE SSD only)
  1 x TPM header
  8 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x CPU OPT Fan connector(s) (1 x 4 -pin)
  6 x Chassis Fan connector(s) (6 x 4 -pin)
  1 x Thunderbolt header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s) (Q-Connector)
  1 x MemOK! button(s)
  1 x Slow Mode switch(es)
  9 x ProbeIt Measurement Points
  3 x Thermal sensor connector(s)
  1 x EZ Plug connector(s) (4-pin Molex power connector)
  1 x Power-on button(s)
  1 x Reset button(s)
  1 x BIOS Switch button(s)
  1 x LN2 Mode jumper(s)
  1 x ROG extension (ROG_EXT) header(s)
  1 x KeyBot Button
  1 x Sonic SoundStage Button
  1 x Safe Boot button
  1 x ReTry button
• Accessories
  User's manual
  I/O Shield
  10 x SATA 6Gb/s cable(s)
  1 x ASUS 3T3R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
  1 x 3-Way SLI bridge(s)
  1 x 4-Way SLI bridge(s)
  1 x SLI bridge(s)
  1 x CrossFire cable(s)
  1 x Q-connector(s) (2 in 1)
  1 x ASUS USB 3.1 Gen 2 CARD(2-ports Type A)
  3 x Thermal sensor cable pack(s)
  1 x 12 in 1 ROG Cable Label(s)
  1 x X-Socket 2 kit
  1 x ROG Door Hanger(s)
  OC Panel Kit:
  - 1 x OC Panel(s)
  - 1 x OC Panel 5.25-inch bay metal case
  - 1 x OC Panel Cable(s)
  - 1 x OC Panel screw pack(s)
• BIOS
  2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Manageability
  WfM2.0, DMI2.7, WOL by PME, PXE
• Support Disc
  Drivers
  ROG GameFirst III
  ROG RAMDisk
  ROG CPU-Z
  ROG Mem TweakIt
  Kaspersky® Anti-Virus
  DAEMON Tools Pro Standard
  ASUS WebStorage
  HomeCloud
  ASUS Utilities
• Form Factor
  Extended ATX Form Factor
  12 inch x 10.7 inch ( 30.5 cm x 27.2 cm )
