DESCRIZIONE

• CPU
  Intel® for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  * Refer to www.asus.com for CPU support list
• Chipset
  Intel® Z270
• Memory
  4 x DIMM, Max. 64GB, DDR4 3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• Graphic
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DisplayPort ports
  - Supports HDMI 2.0 with max. resolution 4096 x 2160 @ 60 / 24 Hz*¹
  - Supports DisplayPort with max. resolution 4096 x 2304 @ 24 Hz / 4096 x 2304 @ 60 Hz
  - Supports High Dynamic Range(HDR),Wide Color Gamut(Rec.2020),HDCP 2.2
  Maximum shared memory of 1024 MB
  Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
  Supports up to 2 displays simultaneously
  DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays
• Multi-GPU Support
  Supports NVIDIA® Quad-GPU SLI™ Technology *⁷
  Supports NVIDIA® 4-Way SLI™ Technology *⁷
  Supports AMD Quad-GPU CrossFireX™ Technology *⁷
  Supports AMD 4-Way CrossFireX Technology *⁷
• Expansion Slots
  4 x PCIe 3.0/2.0 x16 (single at x16, dual at x16/x16 mode, triple at x16/x8/x8 mode or quad x8/x8/x8/x8 mode)
  1 x PCIe x4 (max at x4 mode)
• Storage
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*²
  1 x M.2 x4 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)*³
  2 x U.2 connector*³
  6 x SATA 6Gb/s port(s)*²
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology*⁴
  Intel® Rapid Storage Technology 15 support
  Intel® Optane™ Memory Ready *⁵
• LAN
  Intel® I210-AT, 1 x Gigabit LAN Controller(s)
  Intel® I219-LM , 1 x Gigabit LAN
  Gigabit Intel® LAN Connection- 802.3az Energy Efficient Ethernet (EEE) appliance
  ASUS Turbo LAN Utility
• Audio
  Realtek® ALC S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3
  - Impedance sense for front and rear headphone outputs
  - Supports : Jack-detection, Multi-streaming
  120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
  Audio Feature :
  - DTS Connect
  - DTS Headphone:X
  - Optical S/PDIF out port(s) at back panel
  - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  - Unique de-pop circuit: Reduces start-up popping noise to audio outputs
  - EMI protection cover to prevent electrical noise to affect the amplifier quality
  - Power pre-regulator: Reduces power input noise to ensure consistent performance
  Separate layer for left and right track, ensuring both sound deliver equal quality
  Premium Japan-made audio capacitors provides warm, natural, and immersive sound with exceptional clarity and fidelity
• USB Ports
  Intel® Z270 Chipset :
  6 x USB 3.1 Gen 1 port(s) (4 at back panel, , 2 at mid-board)
  Intel® Z270 Chipset :
  6 x USB 2.0/1.1 port(s) (4 at back panel, , 2 at mid-board)
  ASMedia® USB 3.1 controller :
  2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A + USB Type-C^TM)
  ASMedia® USB 3.1 controller :
  1 x USB 3.1 front panel connector port(s)
• Special Features
  OC Design - ASUS PRO Clock Technology
  - Full BCLK range for extreme overclocking performance
  5-Way Optimization by Dual Intelligent Processors 5
  - Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ Power Control, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.
  Gamer's Guardian:
  - SafeSlot
  ASUS TPU :
  - Auto Tuning
  - GPU Boost
  ASUS EPU :
  - EPU
  ASUS Digital Power Design :
  - Industry leading Digital 8 + 4 + 2 Phase Power Design
  ASUS Exclusive Features :
  - USB BIOS Flashback
  - MemOK!
  - AI Suite 3
  - Ai Charger
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  - Turbo LAN
  - Crystal Sound 3
  - EZ XMP ASUS Exclusive Features
  ASUS Quiet Thermal Solution :
  - Stylish Fanless Design Heat-pipe solution
  - ASUS Fan Xpert 4
  ASUS EZ DIY :
  - ASUS CrashFree BIOS
  - ASUS EZ Flash 3
  - ASUS USB BIOS Flashback
  CPU Installation Tool
  - Three-step simplicity and safety
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-Code
  - ASUS Q-LED (CPU, DRAM, VGA, HDD LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
  - ASUS Q-Connector
  Performance Optimization :
  - Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control
  Turbo App
  Key Express
  M.2 and U.2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M.2 and U.2)
• Back I/O Ports
  1 x DisplayPort
  1 x HDMI
  2 x LAN (RJ45) port(s)
  1 x USB 3.1 Gen 2 (teal blue)Type-A
  1 x USB 3.1 USB Type-C^TM
  4 x USB 3.1 Gen 1
  4 x USB 2.0
  1 x Optical S/PDIF out
  1 x USB BIOS Flashback Button(s)
  1 x 8-channel Audio I/O
• Internal I/O Ports
  1 x RGB Header(s)
  1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  2 x M.2 Socket 3
  6 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s)
  1 x CPU OPT Fan connector(s)
  3 x Chassis Fan connector(s) ()
  1 x AIO_PUMP connector
  1 x Thunderbolt header(s)
  2 x 8-pin EATX 12 V Power connector
  1 x 6-pin EATX 12 V_1 Power connector(s)
  1 x 24-pin EATX Power connector(s)
  1 x EZ XMP switch
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s) (Q-Connector)
  1 x 5-pin EXT_FAN(Extension Fan) connector
  1 x MemOK! button(s)
  1 x Power-on button(s)
  1 x Clear CMOS button(s)
  1 x 14-1 pin TPM connector
  2 x U.2 connector
  1 x COM port header
  1 x USB 3.1 Gen 2 front panel connector
• Accessories
  User's manual
  ASUS Q-Shield
  1 x 2-Way SLI bridge(s)
  1 x COM port cable(s)
  6 x SATA 6Gb/s cable(s)
  2 x M.2 Screw Package
  1 x CPU installation tool
  1 x Supporting DVD
  1 x 3-Way SLI bridge(s)
  1 x 4-Way SLI bridge(s)
  1 x Q-Connector
  1 x 2-port USB 2.0 module(s)
  1 x Extension Cable for RGB strips (80 cm)
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Manageability
  WfM 2.0, DMI 3.0, WOL by PME, PXE
• Operating System
  Windows® 10
  Windows® 8.1 64-bit *⁶
  Windows® 7 64-bit *⁶
• Form Factor
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
