DESCRIZIONE

• CPU
  Intel® Socket 2066 Core™ X-Series Processors
  * Refer to www.asus.com for CPU support list
  * The Intel® Turbo Boost Technology 3.0 Support Depends on the CPU types.
• Chipset
  Intel® X299
• Memoria
  Intel® Core™ X-series Processors (6-core above)
  8 x DIMM, Max. 128GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  Intel® Core™ X-series Processors (4-core)
  4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• Supporto Multi-GPU
  Supports NVIDIA® Quad-GPU SLI™ Technology
  Supports NVIDIA® 3-Way SLI™ Technology
  Supports NVIDIA® 2-Way SLI™ Technology
  Supports AMD Quad-GPU CrossFireX™ Technology
  Supports AMD 3-Way CrossFireX™ Technology
  Supports AMD 2-Way CrossFireX Technology
• Slot di Espansione
  44-Lane CPU-
  Intel® Core™ X-Series Processors Family
  3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
  2 x PCIe 3.0 x4 (max at x4 mode) *¹
  28-Lane CPU-
  Intel® Core™ X-Series Processors Family
  3 x PCIe 3.0/2.0 x16 (x16, x16/x8, x16/x8/x1)
  2 x PCIe 3.0 x4 (max at x4 mode) *¹
  16-Lane CPU-
  Intel® Core™ X-Series Processors Family
  3 x PCIe 3.0/2.0 x16 (x16, x8/x8, x8/x8/x1)
  2 x PCIe 3.0 x4 (max at x4 mode) *¹
• Storage
  Intel® Core™ X-Series Processors Family :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  8 x SATA 6Gb/s port(s)
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology, Intel Rapid Start Technology
  Intel® Optane™ Memory Ready
• LAN
  Intel® I219V
  Anti-surge LANGuard
  ROG GameFirst IV
• Wireless Data Network
  Wi-Fi 802.11 a/b/g/n/ac
• Bluetooth
  Bluetooth V4.2
• Audio
  SupremeFX 8-Channel High Definition Audio CODEC S1220A
  - Dual Headphone Amplifiers
  - Impedance sense for front and rear headphone outputs
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - High quality 120 dB SNR stereo playback output and 113 dB SNR stereo playback input
  - SupremeFX Shielding Technology
  - Supports up to 32-Bit/192kHz playback *²
  Audio Feature :
  - SupremeFX Shielding™ Technology
  - Optical S/PDIF out port(s) at back panel
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
  - Sonic Radar III
  - Sonic Studio III
• Porte USB
  ASMedia® USB 3.1 Gen 2 controller :
  1 x USB 3.1 Gen 2 front panel connector port(s)
  ASMedia® USB 3.1 Gen 2 controller :
  2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A + USB Type-C^TM)
  Intel® X299 Chipset :
  8 x USB 3.1 Gen 1 port(s) (4 at back panel, +blue, 4 at mid-board)
  Intel® X299 Chipset :
  4 x USB 2.0 port(s) (2 at back panel, , 2 at mid-board)
• Caratteristiche Overclock
  ROG RAMCache II
  ROG CPU-Z
  ROG CloneDrive
  Overwolf
  GameFirst IV
  ROG Aura
  - Aura Lighting Control
  - Aura RGB Strip Headers
• Caratteristiche Speciali
  OC Design - ASUS PRO Clock Technology

  ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
  - 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo Core App
  AURA :
  - Aura Lighting Control
  - Aura RGB Strip Headers
  - Aura Lighting Effects Synchronization with compatible ASUS ROG devices
  - Aura Addressable Strip Header(s)
  ASUS Exclusive Features :
  - USB BIOS Flashback
  - AI Suite 3
  - Ai Charger
  - Onboard Button : Power
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  ASUS EZ DIY :
  - ASUS EZ Flash 3
  - ASUS USB BIOS Flashback
  - ASUS UEFI BIOS EZ Mode
  - Multi-language BIOS
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-Code
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
  - ASUS Q-Connector
  Gaming Aesthetics :
  - 3D printing friendly
  - AURA-RGB Lighting
  M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)
• Porte I/O Posteriori
  1 x LAN (RJ45) port(s)
  2 x USB 3.1 Gen 2 Type-A + USB Type-C^TM
  4 x USB 3.1 Gen 1 (blue)
  2 x USB 2.0 (one port can be switched to USB BIOS Flashback)
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x USB BIOS Flashback Button(s)
  1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.0/3.0+HS)
• I/O Interne
  1 x Aura Addressable Strip Header(s)
  1 x AAFP connector
  2 x Aura RGB Strip Headers
  2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  8 x SATA 6Gb/s connector(s)
  1 x M.2_FAN connector ()
  1 x VROC_HW_Key ()
  1 x CPU Fan connector(s)
  1 x CPU OPT Fan connector(s)
  2 x Chassis Fan connector(s)
  1 x AIO_PUMP connector
  1 x W_PUMP+ connector
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x Front panel connector(s)
  1 x System panel(s) (Q-Connector)
  1 x 5-pin EXT_FAN(Extension Fan) connector
  1 x Thermal sensor connector(s)
  1 x Power-on button(s)
  1 x Clear CMOS jumper(s)
  1 x USB 3.1 Gen 2 front panel connector
  1 x CPU_OV jumper
• Accessori
  User's manual
  ASUS Q-Shield
  1 x Vertical M.2 bracket set
  4 x SATA 6Gb/s cable(s)
  1 x M.2 Screw Package
  1 x Supporting DVD
  1 x SLI HB BRIDGE(2-WAY-M)
  1 x Q-Connector
  1 x 10-in-1 ROG cable label
  1 x M.2 screw kit (long screw and mount)
  1 x Thermal sensor cable pack(s)
  1 x Cable ties pack(s)
  ROG Fan Label
  1 x Extension Cable for RGB strips (80 cm)
  1 x 3D printing mount package
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS,
  ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information
• Gestibilità
  WfM 2.0, DMI 3.0, WOL by PME, PXE
• Disco di Supporto
  Drivers
  ASUS Utilities
  EZ Update
  Anti-virus software (OEM version)
• Sistema Operativo
  Windows® 10 64-bit
• Dimensioni Scheda
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
