DESCRIZIONE

• CPU
  Intel® Socket 2066 Core™ X-Series Processors
  * The Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
• Chipset
  Intel® X299
• Memory
  Intel® Core™ X-series Processors (6-core above)
  8 x DIMM, Max. 128GB, DDR4 4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  Intel® Core™ X-series Processors (4-core)
  4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
• Multi-GPU Support
  Supports NVIDIA® Quad-GPU SLI™ Technology
  Supports NVIDIA® 3-Way SLI™ Technology
  Supports NVIDIA® 2-Way SLI™ Technology
  Supports AMD Quad-GPU CrossFireX™ Technology
  Supports AMD 3-Way CrossFireX™ Technology
• Expansion Slots
  44-Lane CPU-
  3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
  1 x PCIe 3.0 x4 (max at x2 mode) *¹
  2 x PCIe 3.0/2.0 x1
  28-Lane CPU-
  2 x PCIe 3.0/2.0 x16 (x16, x16/x8)
  1 x PCIe 3.0 x4 (max at x2 mode) *¹
  2 x PCIe 3.0/2.0 x1
  16-Lane CPU-
  2 x PCIe 3.0/2.0 x16 (x16 or dual x8)
  1 x PCIe 3.0 x4 (max at x2 mode) *¹
  2 x PCIe 3.0/2.0 x1
• Storage
  Intel® X299 Chipset :
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
  6 x SATA 6Gb/s port(s)
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology
  Intel® Rapid Storage Technology 15 support
  Support Intel^® Rapid Storage Technology enterprise 5.1 for X-Series(6-core and above) CPU RAID
  Intel® Optane™ Memory Ready
• LAN
  Intel® I219V, 1 x Gigabit LAN Controller(s), featuring Turbo LAN
  ASUS Turbo LAN Utility
• Audio
  Realtek® ALC S1220A 8-Channel High Definition Audio CODEC
  - Impedance sense for front and rear headphone outputs
  - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  Audio Feature :
  - Optical S/PDIF out port(s) at back panel
  - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
  - Unique de-pop circuit: Reduces start-up popping noise to audio outputs
  Separate layer for left and right track, ensuring both sound deliver equal quality
• USB Ports
  ASMedia® USB 3.1 Gen 2 controller :
  2 x USB 3.1 Gen 2 port(s) (Type-A)
  Intel® X299 Chipset :
  8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board)
  Intel® X299 Chipset :
  6 x USB 2.0 port(s) (4 at back panel, , 2 at mid-board)
• Special Features
  OC Design - ASUS PRO Clock Technology

  TUF Features:
  TUF ENGINE! Power Design :
  - 7 +1 Digital Phase Power Design
  - TUF Components (Choke, Cap. & MOSFET; certified by military-standard)
  Ultimate COOL! Thermal Solution :
  - TUF Thermal Armor
  - Thermal Radar 3
  Safe & Stable! Guardian Angel :
  - TUF ESD Guards 2
  - TUF LANGuard
  AURA :
  - Aura Lighting Control
  - Aura Lighting Effects Synchronization with compatible ASUS ROG devices
  ASUS Exclusive Features :
  - MemOK!
  - AI Suite 3
  - Ai Charger
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  - Turbo LAN
  File Transfer
  - Cloud GO!
  - File Transfer
  ASUS EZ DIY :
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  - Multi-language BIOS
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED, HDD LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
  - ASUS Q-Connector
• Back I/O Ports
  1 x PS/2 keyboard/mouse combo port(s)
  1 x LAN (RJ45) port(s)
  2 x USB 3.1 Gen 2 Type-A
  4 x USB 3.1 Gen 1
  4 x USB 2.0
  1 x Optical S/PDIF out
  5 x Audio jack(s)
• Internal I/O Ports
  1 x AAFP connector
  2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x COM port(s) connector(s)
  6 x SATA 6Gb/s connector(s)
  1 x M.2_FAN connector
  1 x VROC_HW_Key
  1 x CPU Fan connector(s)
  1 x CPU OPT Fan connector(s)
  2 x Chassis Fan connector(s)
  1 x AIO_PUMP connector
  1 x H_AMP fan connector
  1 x W_PUMP+ connector
  1 x Thunderbolt header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x System panel(s) (Q-Connector)
  1 x MemOK! button(s)
  1 x Thermal sensor connector(s)
  1 x Clear CMOS jumper(s)
  1 x 5-pin EXT_FAN(Extension Fan) connector
  2 x 3D Mount screw port(s)
  1 x CPU_OV jumper
• Accessories
  User's manual
  ASUS Q-Shield
  1 x Vertical M.2 bracket set
  4 x SATA 6Gb/s cable(s)
  1 x M.2 Screw Package
  1 x Supporting DVD
  1 x SLI HB BRIDGE(2-WAY-M)
  1 x Q-Connector
  1 x TUF Certification card(s)
  1 x TUF 5 Year Warranty manual(s) (by region)
  1 x TUF Inside sticker(s)(white)
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS,
  ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability
  WfM 2.0, DMI 3.0, WOL by PME, PXE
• Support Disc
  Drivers
  ASUS Utilities
  EZ Update
  Anti-virus software (OEM version)
• Operating System
  Windows® 10 64-bit
• Form Factor
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm
