DESCRIZIONE

• APU	FM2+ Socket: AMD A series processors AMD Athlon™ series processors (Please refer "CPU Support List" for more information.)
  Chipset	AMD A88X
  Memoria	4 x DDR3 DIMM sockets supporting up to 64 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Architettura di memoria a doppio canale Support for DDR3 2133/1866/1600/1333 MHz memory modules Support for AMD Memory Profile (AMP) / Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.)
  Grafica integrata	Integrated Graphics Processor: * To use the onboard graphics ports, you must install an AMD APU with integrated graphics. 1 x D-Sub port, supporting a maximum resolution of 1920x1200 1 x DVI-D port, supporting a maximum resolution of 2560x1600 * Support for 2560x1600 resolution requires both a monitor and cable that support Dual Link DVI. * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x2160 * Support for HDMI 1.4a version. * The resolution of 4096x2160 can be supported when using an FM2+ APU; the maximum resolution supported is 1920x1200 when using an FM2 APU. Support for up to 3 displays at the same time Maximum shared memory of 2 GB
  Audio	Realtek® ALC892 codec Audio a 2/4/5.1/7.1 canali Supporta uscite S/PDIF Audio ad alta definizione
  LAN	Realtek® GbE LAN chip (10/100/1000 Mbit)
  Slot di Espansione	1 Slot PCI Express 16X, operante a 16X *Per migliori Performance, se solo una Scheda Video PCI è installata, assicurati che questi sia inserita in uno Slot PCI Express 16X. 1 x Slot PCI Express x16, funzionante a x4 (PCIEX4) (Lo Slot PCIEX16 è conforme allo standard PCI Express 3.0.) *To support PCI Express 3.0, you must install an FM2+ APU. 3 x PCI Express x1 slots (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.) 2 x PCI slots * The PCIEX4 slot shares bandwidth with the PCIEX1_2/3 slots. When the PCIEX1_2/3 slots is populated, the PCIEX4 slot will operate at up to x2 mode.
  Tecnologia Multi GPU	Support for AMD Eyefinity technology Support for 2-Way AMD CrossFire™ Technology Supporta la tecnologia AMD Dual Graphics Solo con le APU AMD A series
  Interfaccia di storage	Chipset: 8 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
  USB	Chipset: 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header) 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) ASMedia® USB 3.1 Controller: 1 x USB Type-C™ port on the back panel, with USB 3.1 support 1 x USB 3.1 Type-A port (red) on the back panel
  Connettori Interni I/O	8 x SATA 6Gb/s connectors 3 x system fan headers 1 Connettore per porte USB 3.0/2.0 2 x Connettori USB 2.0/1.1 1 x Trusted Platform Module (TPM) header 1 Connettore di Alimentazione ATX ad 8-pin 1 Connettore per Pannello Frontale 1 Connettore di Alimentazione ATX a 24-pin 1 Connettore per uscite Audio Frontali 1 Porta seriale 1 x APU fan header 1 x Clear CMOS jumper 1 x S/PDIF Out header
  Pannello Posteriore I/O	4 x USB 2.0/1.1 ports 2 x USB 3.0/2.0 ports 1 x optical S/PDIF Out connector 1 x USB Type-C™ Port, with USB 3.1 support 1 Connessione per Mouse e Tastiera PS/2 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) 1 x USB 3.1 Type-A port (red) 1 Porta RJ-45 1 Porta HDMI 1 x Porta D-Sub 1 x Porta DVI-D
  I/O Controller	iTE® I/O Controller Chip
  Monitoraggio H/W	Rilevamento dei voltaggi del sistema Rilevamento della temperatura dell' APU Avviso di rilevamento Fan dell' APU Avviso di surriscaldamento APU Avviso di malfunzionamento ventola APU Controllo ventola APU
  BIOS	Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 2 x 64 Mbit flash Support for DualBIOS™
  Altre Caratteristiche	Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. Support for Smart Switch Supporta il Q-Flash Support for Xpress Install Support for @BIOS Support for Cloud Station USB Blocker Smart TimeLock System Information Viewer Game Controller Supporta EasyTune * Le funzioni disponibili possono variare da modello a modello. Support for Smart Recovery 2 Support for On/Off Charge
  Software in Bundle	Norton® Internet Security (OEM version)
  Sistema Operativo	Support for Windows 10/8.1 64-bit Support for Windows 7 32-bit/64-bit
  Caratteristiche Fisiche	ATX Form Factor; 30.5cm x 23.5cm
  Note	A causa delle diverse condizioni di supporto per Linux fornito da fornitori di chipset, scaricare il driver Linux dal sito web fornitori di chipset. La maggior parte dei Vendor hardware/software non possono più offrire i driver per supportare Win9X/ME/2000/XP. Se i driver non sono disponibili presso i fornitori, aggiornateli sul sito GIGABYTE.
