DESCRIZIONE

• CPU
  Intel® Socket 1151 for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  * Refer to www.asus.com for CPU support list
• Chipset
  Intel® Z270
• Memory
  2 x DIMM, Max. 32GB, DDR4 4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400/2133 MHz Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
• Graphic
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DisplayPort ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
  - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
• Expansion Slots
  1 x PCIe 3.0/2.0 x16
• Storage
  Intel® Z270 Chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*¹
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*¹
  4 x SATA 6Gb/s port(s)
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology*²
  Intel® Optane™ Memory Ready *³
• LAN
  Intel® I219V
  Anti-surge LANGuard
  ROG GameFirst Technology
  Dual interconnect between the integrated Media Access Controller (MAC) and physical layer (PHY)
• Wireless Data Network
  Wi-Fi 802.11 a/b/g/n/ac
  Supports dual band frequency 2.4/5 GHz
  Supports MU-MIMO
• Bluetooth
  Bluetooth V4.1*⁴
• Audio
  ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
  - Dual Headphone Amplifiers
  - Impedance sense for front and rear headphone outputs
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  - SupremeFX Shielding Technology
  - Supports up to 32-Bit/192kHz playback *⁵
  Audio Feature :
  - SupremeFX Shielding™ Technology
  - Optical S/PDIF out port(s) at back panel
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
  - Sonic Radar III
  - Sonic Studio III
• USB Ports
  Intel® Z270 Chipset :
  6 x USB 3.1 Gen 1 port(s) (4 at back panel, blue, 2 at mid-board)
  Intel® Z270 Chipset :
  4 x USB 2.0 port(s)
  ASMedia® USB 3.1 controller : *⁶
  1 x USB 3.1 front panel connector port(s)
• ROG Exclusive Features
  ROG RAMCache II
  ROG CloneDrive
  Overwolf
  GameFirst IV
• Special Features
  OC Design - ASUS PRO Clock Technology
  - Full BCLK range for extreme overclocking performance
  5-Way Optimization by Dual Intelligent Processors 5
  - Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ Power Control, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.
  TPU
  - Auto Tuning, TurboV, GPU Boost
  - Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors
  Gamer's Guardian:
  - DRAM Overcurrent Protection
  - Stainless Steel Back I/O
  - Highly Durable Components
  - DIGI+ VRM
  - SafeSlot
  ASUS EPU :
  - EPU
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  - ESD Guards
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
  Gaming Aesthetics :
  - AURA-RGB Lighting
  Digi+VRM
• Back I/O Ports
  1 x DisplayPort
  1 x HDMI
  1 x LAN (RJ45) port(s)
  4 x USB 3.1 Gen 1 Type-A + USB Type-C^TM *⁸
  4 x USB 2.0
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.1)
• Internal I/O Ports
  1 x RGB Header(s)
  1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
  4 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s)
  1 x Chassis Fan connector(s)
  1 x AIO_PUMP connector
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s)
  1 x Clear CMOS jumper(s)
  1 x 14-1 pin TPM connector
  1 x Thermal sensor connector
  1 x USB 3.1 Gen 2 front panel connector
• Accessories
  User's manual
  M.2 2242 mounting kit
  I/O Shield
  4 x SATA 6Gb/s cable(s)
  2 x M.2 Screw Package
  1 x CPU installation tool
  1 x Supporting DVD
  1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
  1 x ROG Strix stickers
  1 x 10-in-1 ROG cable label
  1 x Extension Cable for RGB strips (80 cm)
  1 x Panel cable
  1 x ROG coaster(s)
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Manageability
  DMI3.0, WOL by PME, PXE
• Operating System
  Windows® 10 64-bit
  Windows® 8.1 64-bit *⁷
  Windows® 7 32-bit *⁷
  Windows® 7 64-bit *⁷
• Form Factor
  Mini ITX Form Factor
  6.7 inch x 6.7 inch ( 17 cm x 17 cm )
