CPU

• Supports 4th Generation Intel^® Core™ i7 / Core™ i5 / Core™ i3 / Pentium^® / Celeron^® processors for LGA 1150 socket
Please refer to CPU Support for compatible CPU; the above description is for reference only.


Chipset

• Intel^® B85 Express



<stronglots< strong="">Slots

• 1 x PCIe 3.0 x16 slot
• 2 x PCIe 2.0 x1 slot
 </stronglots<>

On-Board SATA

• SATAIII controller integrated in Intel^® B85 chipset
- Up to 6Gb/s transfer speed.
- Supports two SATAIII port (SATA1~2) by B85

• SATAII controller integrated in Intel^® B85 chipset
- Up to 3Gb/s transfer speed.
- Supports two SATAII ports (SATA3~4) by B85


USB

• 4 x USB 3.0 ports by Intel^®  B85



Audio

• Chipset integrated by Realtek^® ALC887
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec


LAN

• Supports one PCI Express LAN 10/100/1000 Fast Ethernet by Realtek^® 8111G


Internal I/O Connectors

- 1 x ATX 24-Pin power connector
- 1 x 4-pin ATX 12V power connector
- CPU x 1 / System x 2 FAN connectors
- 1 x Clear CMOS jumper
- 2 x SATAIII connectors
- 2 x SATAII connectors
- 1 x USB 3.0 connector
- 2 x USB 2.0 connectors
- 1 x Serial port connector
- 1 x Trusted Platform Module (TPM) header
- 1 x Front Panel Audio connector
- 1 x Chassis Intrusion connector


Back Panel I/O Ports

- 1 x PS/2 keyboard port / mouse port
- 4 x USB 2.0 ports
- 2 x USB 3.0 ports
- 1 x RJ45 LAN Jack
- 1 x parallel port
- 1 x 3 in 1 audio jack
- 1 x DVI-D port with max. resolution up to 1920x1200 @60Hz
- 1 x Graphic card port with max. resolution up to 1920x1200 @60Hz



BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.


Dimension

• 228 x 226mm Micro-ATX Form Factor


Mounting

•  6 mounting holes.
