DESCRIZIONE

• Type

  Product Type

  mSATA

  Interface

  SATA 6Gb/s Interface, compatible with SATA 3Gb/s & SATA 1.5Gb/s interface

• Application

  Consumer

  Client PCs

• Storage

  Capacity

  1000 GB* *Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

• Key Features

  Sequential Read Speed

  Up to 540 MB/s Sequential Read * *Performance may vary based on system hardware & configuration

  Sequential Write Speed

  Up to 520 MB/s Sequential Write * *Performance may vary based on system hardware & configuration

  Random Read Speed

  Random Read (4KB, QD32):Up to 97,000 IOPS Random Read * Performance may vary based on system hardware & configurationRandom Read (4KB, QD1): Up to 10,000 IOPS Random Read * Performance may vary based on system hardware & configuration

  Random Write Speed

  Random Write (4KB, QD32): Up to 88,000 IOPS Random Write * *Performance may vary based on system hardware & configurationRandom Write (4KB, QD1): Up to 40,000 IOPS Random Write * Performance may vary based on system hardware & configuration

  Memory Speed

  Samsung 32 layer 3D V-NANDSamsung 1GB Low Power DDR2 SDRAM

  Controller

  Samsung MEX Controller

  Trim Support

  Yes

  AES Encryption

  AES 256 bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)

  S.M.A.R.T. Support

  Yes

  GC (Garbage Collection)

  Auto Garbage Collection Algorithm

  WWN Support

  World Wide Name supported

  Device Sleep Mode Support

  Yes

  Internal Storage

  Yes

  Temperature proof

  Yes

• General

  Power Consumption (W)

  50 MW * Actual power consumption may vary depending on system hardware & configuration Average: 4.3 W *Maximum: 5.7 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration

  Voltage

  3V ± 5% Allowable voltage

  Reliability (MTBF)

  1.5 Million Hours Reliability (MTBF)

• Environmental Specs

  Operating Temperature

  32ºF - 158ºF

  Shock

  1500G & 0.5ms (Half sine)

• Form Factor

  Product

  mSATA

• Dimensions (W x D x H)

  Product

  1.18" x 2" x 0.15"

• Weight

  Product

  0.02

• Software

  Management SW

  Magician Software

• Warranty

  Product

  5 Years Limited Warranty or 150TBW Limited Warranty
