DESCRIZIONE

• CPU
  Intel® Socket 1151 for 6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.


• Chipset
  Intel® B150
• Memory
  2 x DIMM, Max. 32GB, DDR4 2133 MHz Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)

  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
• Graphic
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DVI-D ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
• Expansion Slots
  1 x PCIe 3.0/2.0 x16 (x16 mode)
• Storage
  Intel® B150 chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)*
  4 x SATA 6Gb/s port(s),
• LAN
  Intel® I219V, 1 x Gigabit LAN Controller(s), GameFirst technology
  Anti-surge LANGuard
• Wireless Data Network
  Wi-Fi 802.11 a/b/g/n/ac
  Supports dual band frequency 2.4/5 GHz
• Bluetooth
  Bluetooth V4.1
• Audio
  SupremeFX 8-Channel High Definition Audio CODEC
  - Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
  - High quality 112 dB SNR stereo playback output
  Audio Feature :
  - SupremeFX Shielding™ Technology
  - Optical S/PDIF out port(s) at back panel
  - Sonic Radar II
• USB Ports
  Intel® B150 chipset :
  5 x USB 3.0/2.0 port(s) (3 at back panel, blue, 2 at mid-board)
  Intel® B150 chipset :
  4 x USB 2.0/1.1 port(s) (2 at back panel, , 2 at mid-board)
• Special Features
  Gamer's Guardian:
  - ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports
  - DRAM Overcurrent Protection
  - Stainless Steel Back I/O
  - Highly Durable Components
  - DIGI+ VRM
  ASUS EPU :
  - EPU
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  - USB 3.0 Boost
  - Disk Unlocker
  Remote Entertainment
  - Media Streamer
  - HyStream
  ASUS Quiet Thermal Solution :
  - Stylish Fanless Design Heat-sink solution
  - ASUS Fan Xpert 2+
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  - Push Notice
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  - ASUS Q-DIMM
  RAMCache
  AURA: RGB Lighting Control
• Operating System Support
  Windows® 10 , 64bit
  Windows® 8.1 , 64bit
  Windows® 7 , 32bit/64bit
• Back I/O Ports
  1 x PS/2 keyboard/mouse combo port(s)
  1 x DVI
  1 x HDMI
  1 x LAN (RJ45) port(s)
  3 x USB 3.0 Type-A + Type-C^TM
  2 x USB 2.0
  1 x Optical S/PDIF out
  6 x Audio jack(s)
• Internal I/O Ports
  1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  1 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices
  1 x TPM header
  4 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x Chassis Fan connector(s) (1 x 4 -pin)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s) (Q-Connector)
  1 x Clear CMOS jumper(s)
  1 x Water Pump header (4-pin)
  1 x 14-1 pin TPM connector
• Accessories
  User's manual
  ASUS Q-Shield
  M.2 2242 mounting kit
  2 x SATA 6Gb/s cable(s)
  1 x M.2 Screw Package
  1 x pack of cable tie
  1 x CPU installation tool
  1 x Supporting DVD
  1 x 12 in 1 Cable Label (s)
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM 2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3,
  CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, F9 Quick Note, Last Modified Log, F12 PrintScreen function, and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability
  WfM 2.0, DMI 3.0, WOL by PME, PXE
• Support Disc
  Drivers
  ASUS Utilities
  ASUS EZ Update
  Anti-virus software (OEM version)
• Form Factor
  Mini ITX Form Factor
  6.7 inch x 6.7 inch ( 17 cm x 17 cm )
