DESCRIZIONE

• CPU
  Intel® for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.


• Chipset
  Intel® H110
• Memory
  2 x SO-DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory
  Supports Intel® Extreme Memory Profile (XMP)

  * Due to Intel® chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th Generation Intel® processors. Higher memory modules will run at the maximum transfer rate of DDR4 2400MHz.
  ** Due to Intel® chipset limitation, DDR4 2133MHz and higher memory modules on 6th Generation Intel® processors will run at the maximum transfer rate of DDR4 2133MHz.
• Graphic
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/LVDS/DisplayPort ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
  - Supports LVDS with max. resolution 1920 x 1200 @ 60 Hz
  - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports up to 2 displays simultaneously
• Storage
  Intel® H110 chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260 storage devices support (both SATA & PCIE mode)
  2 x SATA 6Gb/s port(s)
• LAN
  Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
  Intel® I219V, 1 x Gigabit LAN
• Audio
  Realtek® ALC887 7.1-Channel High Definition Audio CODEC *¹
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
• USB Ports
  Intel® H110 chipset :
  4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
  Intel® H110 chipset :
  5 x USB 2.0/1.1 port(s) (5 at mid-board)
• Special Features
  ASUS 5X Protection II :
  - ASUS LANGuard - 2.5X higher surge tolerance
  - ASUS Overvoltage Protection - World-class circuit-protecting power design
  - ASUS DIGI+ VRM - 3 Phase digital power design
  - ASUS DRAM Overcurrent Protection - Prevents damage from short circuits
  - ASUS Stainless-Steel Back I/O - 3X corrosion-resistance for greater durability
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  - Mobo Connect
  - PC Cleaner
  ASUS Quiet Thermal Solution :
  - ASUS Fan Xpert
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  - Push Notice
  100% All High-quality Conductive Polymer Capacitors
  Media Streamer
• Operating System Support
  Windows® 10 , 64bit
  Windows® 8.1 , 64bit
  Windows® 7 , 32bit/64bit *²
• Back I/O Ports
  1 x DisplayPort
  1 x HDMI
  2 x LAN (RJ45) port(s)
  4 x USB 3.1 Gen 1 (blue)
  2 x Audio jack(s)
  1 x DC power connector(s)
• Internal I/O Ports
  3 x USB 2.0 connector(s) support(s) additional 5 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260 storage devices support (both SATA & PCIE mode)
  1 x COM port(s) connector(s)
  2 x SATA 6Gb/s connector(s)
  1 x SATA power connector(s)
  1 x CPU Fan connector(s)
  1 x Chassis Fan connector(s) ()
  1 x Front panel audio connector(s) (AAFP)
  1 x Chassis Intrusion connector(s)
  1 x Clear CMOS jumper(s)
  1 x 2-pin internal DC power connector
  1 x Stereo speaker connector
  1 x DMIC header
  1 x Backlight inverter voltage selection header
  1 x FPD brightness header
  1 x Panel voltage selection header
  1 x Panel off header
  1 x LVDS connector(s)
  1 x 14-1 pin TPM connector
  1 x System panel connector
  1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices support or PCIE/USB mode
• Accessories
  User's manual
  I/O Shield
  Thin Mini ITX I/O Shield
  1 x SATA power cable
  2 x SATA 6Gb/s cable(s)
  2 x M.2 Screw Package
  1 x Supporting DVD
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM 2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3,CrashFree BIOS 3, My Favorites, Quick Note, Last Modified Log, F12 PrintScreen function,F6 Qfan Control
• Manageability
  WfM 2.0, DMI 3.0, WOL by PME
• Support Disc
  Drivers
  ASUS Utilities
  ASUS EZ Update
  Anti-virus software (OEM version)
• Form Factor
  Thin Mini ITX Form Factor
  6.7 inch x 6.7 inch ( 17 cm x 17 cm )
