DESCRIZIONE

• CPU
  Intel® Socket 1151 for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.


• Chipset
  Intel® H270
• Memory
  2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)

  * Due to Intel® chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th Generation Intel® processors. Higher memory modules will run at the maximum transfer rate of DDR4 2400MHz.
  ** Due to Intel® chipset limitation, DDR4 2133MHz and higher memory modules on 6th Generation Intel® processors will run at the maximum transfer rate of DDR4 2133MHz.
• Graphic
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DisplayPort 1.2 ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
  - Supports DisplayPort 1.2 with max. resolution 4096 x 2304 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
• Expansion Slots
  1 x PCIe 3.0/2.0 x16
• Storage
  Intel® H270 Chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)*
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*
  Support Raid 0, 1, 5, 10
  Intel® Rapid Storage Technology 15 support*¹
  4 x SATA 6Gb/s port(s),
  Intel® Optane™ Memory Ready *²
• LAN
  Intel® I219V, 1 x Gigabit LAN Controller(s), Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY)
  Realtek® RTL8111H, 1 x Gigabit LAN
  Anti-surge LANGuard
  ROG GameFirst IV
• Wireless Data Network
  Wi-Fi 802.11 a/b/g/n/ac
  Supports dual band frequency 2.4/5 GHz
  Supports MU-MIMO
• Bluetooth
  Bluetooth V4.1*³
• Audio
  ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
  - Dual Headphone Amplifiers
  - Impedance sense for front and rear headphone outputs
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  - SupremeFX Shielding Technology
  - Supports up to 32-Bit/192kHz playback *⁴
  Audio Feature :
  - Optical S/PDIF out port(s) at back panel
  - Sonic Radar III
  - Sonic Studio III
• USB Ports
  Intel® H270 Chipset :
  8 x USB 3.1 Gen 1 port(s) (6 at back panel, +blue, 2 at mid-board)
• ROG Exclusive Features
  ROG RAMCache II
  ROG CPU-Z
  ROG CloneDrive
  Overwolf
  GameFirst IV
  ROG Aura
  - Aura Lighting Control
  - Aura RGB Strip Headers
• Special Features
  Gamer's Guardian:
  - ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports
  - DRAM Overcurrent Protection
  - Highly Durable Components
  - DIGI+ VRM
  - SafeSlot
  ASUS EPU :
  - EPU
  AURA :
  - Aura Lighting Control
  - Aura RGB Strip Headers
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  ASUS Quiet Thermal Solution :
  - ASUS Fan Xpert 4 Core
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
• Back I/O Ports
  1 x DisplayPort
  1 x HDMI
  2 x LAN (RJ45) port(s)
  6 x USB 3.1 Gen 1 (blue)
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x Wi-Fi antenna port(s)
• Internal I/O Ports
  1 x Aura RGB Strip Header
  1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
  1 x TPM connector(s)
  4 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x Chassis Fan connector(s) (1 x 4 -pin)
  1 x AIO_PUMP connector (1 x 4 -pin)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x Internal speaker connector(s)
  1 x System panel(s)
  1 x Clear CMOS jumper(s)
• Accessories
  User's manual
  M.2 2242 mounting kit
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  2 x M.2 screws
  1 x pack of cable tie
  1 x Supporting DVD
  1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n compliant)
  1 x ROG Strix stickers
  1 x 10-in-1 ROG cable label
  1 x Extension Cable for RGB strips (80 cm)
  1 x Panel cable
• BIOS
  1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Operating System
  Windows® 10 64-bit
  Windows® 8.1 64-bit *⁵
  Windows® 7 32-bit *⁵
  Windows® 7 64-bit *⁵
• Form Factor
  Mini ITX Form Factor
  6.7 inch x 6.7 inch ( 17 cm x 17 cm )
