DESCRIZIONE

• Processore
   Socket:AM4

  1. AMD Ryzen™ processor
  2. AMD 7^th Generation A-series/ Athlon™ processor

  (Please refer "CPU Support List" for more information.)
• Chipset
  1. AMD B350
• Memoria
  1. 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
  2. Architettura di memoria a doppio canale
  3. Support for DDR4 3200(O.C.) / 2933(O.C.) / 2667* / 2400 / 2133 MHz memory modules
  4. * Support for higher than DDR4 2667 MHz may vary by CPU.
  5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  7. Supporta le memorie dotate di Profilo XMP

  (Please refer "Memory Support List" for more information.)
• Grafica integrata
  Integrated Graphics Processor:

  1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
  2. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
     * The DVI-D port does not support D-Sub connection by adapter.
  3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
     * Support for HDMI 1.4a version.
  4. Support for up to 3 displays at the same time
  5. Maximum shared memory of 2 GB

  * Actual support may vary by CPU.
• Audio
  1. Realtek® ALC887 codec
  2. Audio ad alta definizione
  3. 2/4/5.1/7.1-channel

     * Per configurare l' audio 7.1 devi usare un modulo frontale HD e abilitare il Multi Channel Audio dal pannello di controllo dei tuoi driver
  4. Supporta uscite S/PDIF
• LAN
  1. Realtek® GbE LAN chip (10/100/1000 Mbit)
• Slot di Espansione
  1. 1 Slot PCI Express 16X,
     operante a 16X

     *Per migliori Performance, se solo una Scheda Video PCI è installata,
     assicurati che questi sia inserita in uno Slot PCI Express 16X.
  2. (Lo Slot PCIEX16 è conforme allo standard PCI Express 3.0.)
  3. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
     (The PCIEX4 slot conforms to PCI Express 2.0 standard.)
  4. 1 x PCI Express x1 slot
     (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.)

  * Actual support may vary by CPU.
• Tecnologia Multi GPU
  1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
• Interfaccia di storage
  Chipset:

  1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4*/x2 SSD support)
  2. * Actual support may vary by CPU.
  3. 6 x SATA 6Gb/s connectors
  4. Support for RAID 0, RAID 1, and RAID 10
  5. * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• USB
  Chipset:

  1. 2 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
  2. 2 x USB 3.1 Gen 1 ports (available through the internal USB header)
  3. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

  CPU:

  1. 4 x USB 3.1 Gen 1 ports on the back panel
• Connettori Interni I/O
  1. 6 x SATA 6Gb/s connectors
  2. 1 Connettore di Alimentazione ATX a 24-pin
  3. 1 Connettore di Alimentazione ATX ad 8-pin
  4. 1 x M.2 Socket 3 connector
  5. 1 Connettore per Ventola della CPU
  6. 1 Connettore per Pannello Frontale
  7. 1 Connettore per uscite Audio Frontali
  8. 1 x S/PDIF Out header
  9. 1 x USB 3.1 Gen 1 header
  10. 2 x Connettori USB 2.0/1.1
  11. 1 x Trusted Platform Module (TPM) header
  12. 1 x Clear CMOS jumper
  13. 1 Porta seriale
  14. 1 x Connettore per System Fan
• Pannello Posteriore I/O
  1. 1 Connessione per Mouse e Tastiera PS/2
  2. 1 x Porta DVI-D
  3. 1 Porta HDMI
  4. 4 x USB 3.1 Gen 1 ports
  5. 2 x USB 3.1 Gen 2 Type-A ports (red)
  6. 1 Porta RJ-45
  7. 2 x USB 2.0/1.1 ports
  8. 3 x audio jacks (Line In, Line Out, Mic In)
  9. 1 x Porta D-Sub
• I/O Controller
  1. iTE® I/O Controller Chip
• Monitoraggio H/W
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Overheating warning
  5. Fan fail warning
  6. Fan speed control
  7. * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
• BIOS
  1. 2 x 128 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Altre Caratteristiche
  1. Support for APP Center
     * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
  2. Supporta il Q-Flash
  3. Support for Xpress Install
  4. 3D OSD
  5. Auto Green
  6. BIOS Setup
  7. Support for Cloud Station
  8. Color Temperature
  9. EasyTune
  10. Fast Boot
  11. Game Boost
  12. Supporto alla tecnologia ON/OFF Charge
  13. Smart Backup
  14. Smart Keyboard
  15. Smart TimeLock
  16. System Information Viewer
  17. USB Blocker
  18. V-Tuner
  19. @ BIOS ™
  20. Ambient LED
• Software in Bundle
  1. Norton® Internet Security (OEM version)
  2. cFosSpeed
• Sistema Operativo
  1. Support for Windows 10 64-bit
  2. Support for Windows 7 64-bit
  3. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
• Caratteristiche Fisiche
  1. Micro ATX Form Factor; 24.4cm x 21.5cm
