DESCRIZIONE

• CPU
  Intel® Socket 1150 for New 4^th Generation Core™ i7/Core™ i5/Core™ i3/Celeron® dual-core/Pentium®/Celeron® Processors
  Supports Intel® 22 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.


• Chipset
  Intel® B85
• Memory
  4 x DIMM, Max. 32GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.

  * Due to Intel® chipset limitation, DDR3 1600 MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600 Mhz.
• Graphic
  Integrated Graphics Processor
  Multi-VGA output support : HDMI/DVI/RGB ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
  Supports up to 3 displays simultaneously
• Expansion Slots
  1 x PCIe 3.0/2.0 x16
  2 x PCIe 2.0 x1
• Storage
  Intel® B85 chipset :
  4 x SATA 6Gb/s port(s), gray
  2 x SATA 3Gb/s port(s), black,
  Supports Intel® Rapid Start Technology, Intel® Smart Connect Technology *¹
• LAN
  Realtek® 8111GR, 1 x Gigabit LAN Controller(s)
• Audio
  Realtek® ALC887-VD2 8-Channel High Definition Audio CODEC *²
  - Supports : Jack-detection, Front Panel Jack-retasking, Anti-pop Function
  Audio Feature :
  - LED-lit Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference, with a gorgeous illuminated trace path
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
• USB Ports
  Intel® B85 chipset :
  4 x USB 3.1 Gen 1 port(s) (2 at back panel, blue, 2 at mid-board)
  Intel® B85 chipset :
  6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)
  ASMedia® USB 3.1 controller :
  1 x USB 3.1/3.0/2.0 port(s) (1 at back panel, navy blue, Type-A)
  ASMedia® USB 3.1 controller :
  1 x USB 3.1 Gen 2 port(s) (1 at back panel, black, USB Type-C^TM)
• Special Features
  ASUS 5X Protection :
  - ASUS DIGI+ VRM - 3 Phase digital power design
  - ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention
  - ASUS ESD Guards - Enhanced ESD protection
  - ASUS High-Quality 5K-Hour Solid Capacitors - 2.5x long lifespan with excellent durability
  - ASUS Stainless Steel Back I/O - 3x more durable corrosion-resistant coating
  ASUS EPU :
  - EPU
  GPU Boost
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger+
  - Anti-Surge
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  - USB 3.1 Boost
  ASUS Quiet Thermal Solution :
  - ASUS Fan Xpert 2
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 2
  - ASUS MyLogo 2
  ASUS Q-Design :
  - ASUS Q-Slot
  - ASUS Q-DIMM
  100% All High-quality Conductive Polymer Capacitors
• Operating System Support
  Windows® 8.1
  Windows® 8
  Windows® 7
• Back I/O Ports
  1 x PS/2 keyboard (purple)
  1 x PS/2 mouse (green)
  1 x DVI-D
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  1 x USB 3.1 Gen 2 (teal blue)Type-A
  1 x USB 3.1 Gen 2 (black)Type-C^TM
  2 x USB 3.1 Gen 1 (blue)
  2 x USB 2.0
  3 x Audio jack(s)
• Internal I/O Ports
  1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x COM port(s) connector(s)
  4 x SATA 6Gb/s connector(s)
  2 x SATA 3Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  2 x Chassis Fan connector(s) (2 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x Internal speaker connector(s)
  1 x System panel(s)
  1 x Chassis Intrusion connector(s)
  1 x Clear CMOS jumper(s)
• Accessories
  User's manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x SCD
• BIOS
  64 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
• Manageability
  WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
• Support Disc
  Drivers
  ASUS Utilities
  ASUS Update
  Anti-virus software (OEM version)
• Form Factor
  mATX Form Factor
  9.2 inch x 8.3 inch ( 23.3 cm x 21.1 cm )
