DESCRIZIONE

• Processore
  1. Support for 7th/6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package
  2. La Cache L3 varia da CPU a CPU
  3. Please refer "CPU Support List" for more information
• Chipset
  1. Intel® Z270 Express Chipset
• Memoria
  1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
  2. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
  3. Architettura di memoria a doppio canale
  4. Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
  5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  7. Supporta le memorie dotate di Profilo XMP

  *Please refer "Memory Support List" for more information
• Grafica integrata
  Integrated Graphics Processor - Intel® HD Graphics support:

  1. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
  2. * Support for DisplayPort 1.2 version.
  3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
     * Support for HDMI 1.4 version.

  Maximum shared memory of 1 GB
• Audio
  1. Realtek® ALC1220 codec
  2. Audio ad alta definizione
  3. Supporta uscite S/PDIF
  4. Audio a 2/4/5.1/7.1 canali
  5. TI Burr Brown® NE5532 operational amplifier
• LAN
  1. Intel® GbE LAN chip (10/100/1000 Mbit)
• Slot di Espansione
  1. 1 Slot PCI Express 16X,
     operante a 16X

     *Per migliori Performance, se solo una Scheda Video PCI è installata,
     assicurati che questi sia inserita in uno Slot PCI Express 16X.
  2. 1 Slot PCI Express 16X, operante a 8X
     * Lo Slot PCI Express 8X condivide la banda con lo slot PCI Express 16X, ragion per cui quando lo slot da 8X è in uso quello da 16X lavora a 8X.
  3. 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
  4. * The PCIEX4_1 slot shares bandwidth with the M2P_32G connector. The PCIEX4_1 slot and M2P_32G connector operate at up to x2 mode when both are populated.
  5. * The PCIEX4_2 slot shares bandwidth with the PCIEX8 and PCIEX16 slots. When the PCIEX4_2 slot is populated, the PCIEX16 slot operates at up to x8 mode and the PCIEX8 operates at up to x4 mode.
  6. 2 x PCI Express x1 slots
  7. (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• Tecnologia Multi GPU
  1. Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies
  2. Support for AMD Quad-GPU CrossFireX™ and 3-Way/2-Way AMD CrossFire™ technologies
• Interfaccia di storage
  Chipset:

  1. 2 x M.2 connectors (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
  2. 1 x U.2 connector
  3. 2 x SATA Express connectors
  4. 6 x SATA 6Gb/s connectors (SATA3 0~5)
  5. Support for RAID 0, RAID 1, RAID 5, and RAID 10
  6. * Refer to "1-10 Internal Connectors," for the installation notices for the PCIEX4_1/M.2/SATA connectors.

  ASMedia® ASM1061 chip:

  1. 2 x SATA 6Gb/s connectors (SATA3 6, 7), supporting AHCI mode only
• USB
  Chipset:

  1. 8 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports onboard, 2 ports available through the internal USB header)
  2. 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

  Chipset+ASMedia® ASM2142 USB 3.1 Gen 2 Controller:

  1. 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support
  2. 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
• Connettori Interni I/O
  1. 1 Connettore di Alimentazione ATX ad 8-pin
  2. 1 Connettore per Ventola della CPU
  3. 1 Connettore per Pannello Frontale
  4. 1 Connettore di Alimentazione ATX a 24-pin
  5. 1 Connettore per uscite Audio Frontali
  6. 1 x Clear CMOS jumper
  7. 1 x S/PDIF Out header
  8. 1 x audio gain control switch
  9. 2 x sistema di ventilazione
  10. 1 x Thunderbolt™ add-in card connector
  11. 1 x U.2 connector
  12. 1 x RGB (RGBW) LED strip extension cable header
  13. 1 x system fan/water cooling pump header
  14. 2 x M.2 Socket 3 connectors
  15. 1 x water cooling CPU fan header
  16. 2 x SATA Express connectors
  17. 1 x 4-pin ATX 12V power connector
  18. 8 x SATA 6Gb/s connectors
  19. 1 x USB 3.1 Gen 1 header
  20. 2 x USB 3.1 Gen 1 ports
  21. 1 x USB 2.0/1.1 header
  22. 1 x OC Touch header
  23. 1 x Pulsante di accensione
  24. 1 x Pulsante di Reset
  25. 1 x Clear CMOS button
  26. 1 x OC Turbo button
  27. 1 x CPU Ratio Down button
  28. 1 x CPU Ratio Up button
  29. 1 x BIOS switch
  30. 1 x DualBIOS™ switch
• Pannello Posteriore I/O
  1. 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
  2. 4 x USB 3.1 Gen 1 ports
  3. 2 x USB 2.0/1.1 ports
  4. 1 x optical S/PDIF Out connector
  5. 1 Porta HDMI
  6. 1 x DisplayPort
  7. 1 Connessione per Mouse e Tastiera PS/2
  8. 1 x USB 3.1 Gen 2 Type-A port (red)
  9. 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
  10. 1 x OC Ignition button
  11. 1 Porta RJ-45
• I/O Controller
  1. iTE® I/O Controller Chip
• Monitoraggio H/W
  1. Voltage detection
  2. Temperature detection
  3. Fan fail warning
  4. Overheating warning
  5. Fan speed detection
  6. Fan speed control
  7. * Whether the fan speed control function is supported will depend on the cooler you install.
• BIOS
  1. Support for DualBIOS™
  2. Use of licensed AMI UEFI BIOS
  3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  4. 2 x 128 Mbit flash
• Altre Caratteristiche
  1. Supporta il Q-Flash
  2. Supporta i dischi con capacità superiore ai 3TB
  3. Support for Xpress Install
  4. Support for APP Center
  5. * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  6. Auto Green
  7. Supporto alla tecnologia ON/OFF Charge
  8. Support for Cloud Station
  9. EasyTune
  10. USB Blocker
  11. Smart TimeLock
  12. Fast Boot
  13. System Information Viewer
  14. V-Tuner
  15. 3D OSD
  16. Smart Keyboard
  17. Smart Backup
  18. BIOS Setup
  19. Color Temperature
  20. Platform Power Management
  21. Game Boost
  22. Easy RAID
  23. RGB Fusion
  24. USB DAC-UP 2
  25. @ BIOS ™
• Software in Bundle
  1. Norton® Internet Security (OEM version)
  2. Intel® Optane™ Memory Ready
  3. cFosSpeed
• Sistema Operativo
  1. Windows® 10 64-bit (for 7th Generation Intel® Processors)
  2. Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
  3. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
• Caratteristiche Fisiche
  1. ATX Form Factor; 30.5cm x 24.4cm
• Box Contents
  1. The motherboard
  2. Motherboard driver disk
  3. User's Manual
  4. Quick Installation Guide
  5. Four SATA cables
  6. I/O Shield
  7. One G Connector
  8. One pack of back I/O dust covers
  9. One GC-SLI2P bridge connector
