DESCRIZIONE

• Processore
  1. Support for 7th/6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package
  2. La Cache L3 varia da CPU a CPU
  3. Please refer "CPU Support List" for more information
• Chipset
  1. Intel® Z270 Express Chipset
• Memoria
  1. 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
  2. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
  3. Architettura di memoria a doppio canale
  4. Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
  5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  7. Supporta le memorie dotate di Profilo XMP

  *Please refer "Memory Support List" for more information
• Grafica integrata
  Integrated Graphics Processor - Intel® HD Graphics support:

  1. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
  2. * Support for DisplayPort 1.2 version.
  3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
     * Support for HDMI 1.4 version.

  Maximum shared memory of 1 GB
• Audio
  1. Realtek® ALC1220 codec
  2. Audio ad alta definizione
  3. Supporta uscite S/PDIF
  4. Audio a 2/4/5.1/7.1 canali
• LAN
  1. Intel® GbE LAN chip (10/100/1000 Mbit)
• Wireless Communication module
  1. Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
  2. Bluetooth 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR
  3. Support for 11ac wireless standard and up to 867 Mbps data rate.
  4. * Actual data rate may vary depending on environment and equipment.
• Slot di Espansione
  1. 1 x PCI Express x16 slot, running at x16
     (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
  2. 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
• Interfaccia di storage
  Chipset:

  1. 1 x M.2 Socket 3 connector on the back of the motherboard (Socket 3, M key, type 2260/2280 SATA and PCIe x4/x2 SSD support)
  2. 4 x SATA 6Gb/s connectors
  3. Support for RAID 0, RAID 1, RAID 5, and RAID 10
  4. * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• USB
  Chipset:

  1. 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB headers)
  2. 2 x USB 2.0/1.1 ports available through the internal USB headers

  Chipset+ASMedia® ASM2142 USB 3.1 Gen 2 Controller:

  1. 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support
  2. 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
• Connettori Interni I/O
  1. 1 Connettore di Alimentazione ATX ad 8-pin
  2. 1 Connettore per Ventola della CPU
  3. 1 Connettore per Pannello Frontale
  4. 1 Connettore di Alimentazione ATX a 24-pin
  5. 1 Connettore per uscite Audio Frontali
  6. 1 x Clear CMOS jumper
  7. 1 x S/PDIF Out header
  8. 2 x sistema di ventilazione
  9. 1 x RGB (RGBW) LED strip extension cable header
  10. 4 Connessioni SATA 6Gb/s
  11. 1 x M.2 Socket 3 connector on the back of the motherboard
  12. 1 x USB 3.1 Gen 1 header
  13. 1 x USB 2.0/1.1 header
  14. 1 x speaker header
  15. 1 x chassis intrusion header
  16. 1 x OC Touch header
• Pannello Posteriore I/O
  1. 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
  2. 4 x USB 3.1 Gen 1 ports
  3. 1 Porta HDMI
  4. 1 x DisplayPort
  5. 1 Connessione per Mouse e Tastiera PS/2
  6. 1 x USB 3.1 Gen 2 Type-A port (red)
  7. 2 x SMA antenna connectors (2T2R)
  8. 1 Porta RJ-45
  9. 3 x audio jacks (Line In, Line Out, Mic In)
• I/O Controller
  1. iTE® I/O Controller Chip
• Monitoraggio H/W
  1. * Whether the fan speed control function is supported will depend on the cooler you install.
  2. Fan speed control
  3. Fan fail warning
  4. Overheating warning
  5. Fan speed detection
  6. Temperature detection
  7. Voltage detection
• BIOS
  1. Use of licensed AMI UEFI BIOS
  2. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  3. 1 x 64 Mbit flash
• Altre Caratteristiche
  1. Supporta il Q-Flash
  2. Supporta i dischi con capacità superiore ai 3TB
  3. Support for Xpress Install
  4. Support for APP Center
  5. * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  6. Auto Green
  7. Supporto alla tecnologia ON/OFF Charge
  8. Support for Cloud Station
  9. EasyTune
  10. USB Blocker
  11. Smart TimeLock
  12. Fast Boot
  13. System Information Viewer
  14. V-Tuner
  15. 3D OSD
  16. Smart Keyboard
  17. Smart Backup
  18. BIOS Setup
  19. Color Temperature
  20. Platform Power Management
  21. Game Boost
  22. Easy RAID
  23. RGB Fusion
  24. @ BIOS ™
• Software in Bundle
  1. Norton® Internet Security (OEM version)
  2. Intel® Optane™ Memory Ready
  3. cFosSpeed
• Sistema Operativo
  1. Windows® 10 64-bit (for 7th Generation Intel® Processors)
  2. Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
  3. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
• Caratteristiche Fisiche
  1. Mini-ITX Form Factor; 17.0cm x 17.0cm
• Box Contents
  1. The motherboard
  2. Motherboard driver disk
  3. I/O Shield
  4. User's Manual
  5. Quick Installation Guide
  6. Wireless module driver disk
  7. Two SATA cables
  8. One antenna
