CPU
• Supports 7th/6th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
|
 |
 Chipset
• Intel® Z270 Chipset
|
|
|
Main Memory
• 4 x DDR4 memory slots, support up to 64GB
- 7th Gen processors support DDR4 3800(OC)/ 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400/ 2133 MHz*
- 6th Gen processors support DDR4 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400(OC)/ 2133 MHz*
• Dual channel memory architecture
• Supports Intel® Extreme Memory Profile (XMP)
|
|
Slots
• 2 x PCIe 3.0 x16 slots (supports x16/x4 mode)
• 4 x PCIe 3.0 x1 slots
|
|
|
Multi-GPU
• Supports 2-Way AMD® CrossFire™ Technology
|
|
|
Onboard Graphics
• 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
• 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
• 1 x DisplayPort, supports a maximum resolution of 4096x2304@24Hz, 2560x1600@60Hz, 3840x2160@60Hz, 1920x1200@60Hz
|
|
Storage
• Intel® Z270 Chipset
• 6 x SATA 6Gb/s ports*
• 1x M.2 slots (Key M)
- Support up to PCIe 3.0 x4 and SATA 6Gb/s
- Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host Card**
- Supports 2242/ 2260 /2280/ 22110 storage devices
- Intel® Optane™ Memory Ready for all M.2 slots
• Supports Intel® Smart Response Technology for Intel Core™ processors
|
|
RAID (optional)
• Intel® Z270 Chipset
• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
|
|
USB
• Intel® Z270 Chipset
- 8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
|
|
Audio
• Realtek® ALC892 Codecr
- 7.1-Channel High Definition Audio
|
|
LAN
• Intel® I219-V Gigabit LAN controller
|
|
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x Clear CMOS jumper
|
|
Back Panel I/O Ports
- 1 x PS/2 mouse & keyboard combo port
- 2 x USB 2.0 ports
- 1 x VGA port
- 1 x DVI-D port
- 1 x DisplayPort
- 1 x LAN (RJ45) port
- 4 x USB 3.1 Gen1 Type-A ports
- 6 x OFC audio jacks
|
|
|
Dimension
• 12.0 in. x 8.9 in. (30.5 cm x 22.5 cm)
• ATX Form Factor
|
|
|
Mounting
• 6 mounting holes
|
