DESCRIZIONE

• Processore
  1. Support for 7th/6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package
  2. La Cache L3 varia da CPU a CPU

  (Per maggiori informazioni fare riferimento alla lista delle CPU supportate)
• Memoria
  1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
  2. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
  3. Architettura di memoria a doppio canale
  4. Support for DDR4 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
  5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  7. Supporta le memorie dotate di Profilo XMP

  (Please refer "Memory Support List" for more information.)
• Grafica integrata
  Integrated Graphics Processor - Intel® HD Graphics support:

  1. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
     * The DVI-D port does not support D-Sub connection by adapter.
  2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
     * Support for HDMI 1.4 version.

  Maximum shared memory of 1 GB
• Audio
  1. Realtek® ALC1220 codec
  2. Audio ad alta definizione
  3. Audio a 2/4/5.1/7.1 canali
  4. Supporta uscite S/PDIF
• LAN
  1. Intel® GbE LAN chip (10/100/1000 Mbit)
• Slot di Espansione
  1. 1 Slot PCI Express 16X,
     operante a 16X

     *Per migliori Performance, se solo una Scheda Video PCI è installata,
     assicurati che questi sia inserita in uno Slot PCI Express 16X.
  2. 1 Slot PCI Express 16X, operante a 8X
     * Lo Slot PCI Express 8X condivide la banda con lo slot PCI Express 16X, ragion per cui quando lo slot da 8X è in uso quello da 16X lavora a 8X.
  3. 1 x Slot PCI Express x16, funzionante a x4 (PCIEX4)
  4. *The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. When the PCIEX1_2 slot or the PCIEX1_3 slot is populated, the PCIEX4 slot will operate at up to x1 mode.
  5. 3 x Slot PCI Express
  6. (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• Tecnologia Multi GPU
  1. Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies
  2. Support for AMD Quad-GPU CrossFireX™ and 3-Way/2-Way AMD CrossFire™ technologies
• Interfaccia di storage
  Chipset:

  1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
  2. 1 x U.2 connector
  3. 2 x SATA Express connectors
  4. 6 x SATA 6Gb/s connectors
  5. Support for RAID 0, RAID 1, RAID 5, and RAID 10
  6. * Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• USB
  Chipset:

  1. 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB headers)
  2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

  Chipset+ASMedia® ASM2142 USB 3.1 Gen 2 Controller:

  1. 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support
  2. 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
  3. 1 x USB 3.1 Gen 2 port available through the internal USB header
• Connettori Interni I/O
  1. 1 x U.2 connector
  2. 2 x SATA Express connectors
  3. 6 x SATA 6Gb/s connectors
  4. 1 Connettore di Alimentazione ATX a 24-pin
  5. 1 Connettore di Alimentazione ATX ad 8-pin
  6. 1 Connettore per Ventola della CPU
  7. 1 x water cooling CPU fan header
  8. 2 x sistema di ventilazione
  9. 1 x system fan/water cooling pump header
  10. 1 x RGB (RGBW) LED strip extension cable header
  11. 1 x M.2 Socket 3 connector
  12. 1 Connettore per Pannello Frontale
  13. 1 Connettore per uscite Audio Frontali
  14. 1 x S/PDIF Out header
  15. 1 x USB 3.1 Gen 2 header
  16. 1 x USB 3.1 Gen 1 header
  17. 2 x Connettori USB 2.0/1.1
  18. 1 Connettore Trusted Platform Module (TPM)
      La
      funzione TPM è opzionale in base alla regolamentazione dei vari stati
  19. 1 x Clear CMOS jumper
• Pannello Posteriore I/O
  1. 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
  2. 1 Connessione per Mouse e Tastiera PS/2
  3. 1 x Porta DVI-D
  4. 1 Porta HDMI
  5. 4 x USB 3.1 Gen 1 ports
  6. 2 x USB 2.0/1.1 ports
  7. 1 x optical S/PDIF Out connector
  8. 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
  9. 1 x USB 3.1 Gen 2 Type-A port (red)
  10. 1 Porta RJ-45
• I/O Controller
  1. iTE® I/O Controller Chip
• Monitoraggio H/W
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Overheating warning
  5. Fan fail warning
  6. Fan speed control
  7. * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
• BIOS
  1. 2 x 64 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Altre Caratteristiche
  1. Support for APP Center
     * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
  2. Supporta il Q-Flash
  3. Support for Xpress Install
  4. 3D OSD
  5. @ BIOS ™
  6. Auto Green
  7. BIOS Setup
  8. Color Temperature
  9. Support for Cloud Station
  10. EasyTune
  11. Easy RAID
  12. Fast Boot
  13. Game Boost
  14. Supporto alla tecnologia ON/OFF Charge
  15. Platform Power Management
  16. RGB Fusion
  17. Smart Backup
  18. Smart Keyboard
  19. Smart TimeLock
  20. System Information Viewer
  21. USB Blocker
  22. USB DAC-UP 2
  23. V-Tuner
• Software in Bundle
  1. Norton® Internet Security (OEM version)
  2. Intel® Optane™ Memory Ready
  3. cFosSpeed
• Sistema Operativo
  1. Windows® 10 64-bit (for 7th Generation Intel® Processors)
  2. Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
  3. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
• Caratteristiche Fisiche
  1. ATX Form Factor; 30.5cm x 24.4cm
