DESCRIZIONE

• Processore
  1. Support for 7th/6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package
  2. La Cache L3 varia da CPU a CPU

  (Please refer "CPU Support List" for more information.)
• Chipset
  1. Intel® B250 Express Chipset
• Memoria
  1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
  2. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
  3. Architettura di memoria a doppio canale
  4. Support for DDR4 2400(O.C.)* / 2133 MHz memory modules
  5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  6. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  7. Supporta le memorie dotate di Profilo XMP

  (Please refer "Memory Support List" for more information.)
  * To support 2400 MHz or XMP memory, you must install a 7th generation processor.
• Grafica integrata
  Integrated Graphics Processor - Intel® HD Graphics support:

  1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
  2. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
     * The DVI-D port does not support D-Sub connection by adapter.
  3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
     * Support for HDMI 1.4 version.

  Support for up to 3 displays at the same time
  Maximum shared memory of 1 GB
• Audio
  1. Audio ad alta definizione
  2. Supporta uscite S/PDIF
  3. Realtek® ALC887 codec
  4. 2/4/5.1/7.1-channel

     * Per configurare l' audio 7.1 devi usare un modulo frontale HD e abilitare il Multi Channel Audio dal pannello di controllo dei tuoi driver
• LAN
  1. Realtek® GbE LAN chip (10/100/1000 Mbit)
• Slot di Espansione
  1. 1 x Slot PCI Express x16, funzionante a x16
  2. 2 x PCI Express x1 slots
  3. (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• Interfaccia di storage
  Chipset:

  1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)
  2. 6 x SATA 6Gb/s connectors
  3. * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• USB
  Chipset:

  1. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
  2. 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB headers)
• Connettori Interni I/O
  1. 1 Connettore di Alimentazione ATX ad 8-pin
  2. 1 Connettore per Ventola della CPU
  3. 1 Connettore per Pannello Frontale
  4. 1 x Connettore per porta Parallela
  5. 1 Connettore di Alimentazione ATX a 24-pin
  6. 1 Connettore per uscite Audio Frontali
  7. 2 x Connettori USB 2.0/1.1
  8. 1 Porta seriale
  9. 1 x Clear CMOS jumper
  10. 1 x S/PDIF Out header
  11. 6 x SATA 6Gb/s connectors
  12. 1 x Trusted Platform Module (TPM) header
  13. 1 x M.2 Socket 3 connector
  14. 1 x USB 3.1 Gen 1 header
  15. 1 x Connettore per System Fan
• Pannello Posteriore I/O
  1. 2 x USB 2.0/1.1 ports
  2. 4 x USB 3.1 Gen 1 ports
  3. 1 Porta HDMI
  4. 1 Connessione per Mouse e Tastiera PS/2
  5. 1 x Porta D-Sub
  6. 1 x Porta DVI-D
  7. 1 Porta RJ-45
  8. 3 x audio jacks (Line In, Line Out, Mic In)
• I/O Controller
  1. iTE® I/O Controller Chip
• Monitoraggio H/W
  1. Overheating warning
  2. Temperature detection
  3. Voltage detection
  4. Fan fail warning
  5. Fan speed detection
  6. Fan speed control
  7. * Whether the fan speed control function is supported will depend on the cooler you install.
• BIOS
  1. 2 x 64 Mbit flash
  2. Support for DualBIOS™
  3. Use of licensed AMI UEFI BIOS
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Altre Caratteristiche
  1. Supporta il Q-Flash
  2. Supporta i dischi con capacità superiore ai 3TB
  3. Support for Xpress Install
  4. Support for APP Center
     * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
  5. Auto Green
  6. Supporto alla tecnologia ON/OFF Charge
  7. Support for Cloud Station
  8. EasyTune
  9. USB Blocker
  10. Smart TimeLock
  11. Fast Boot
  12. System Information Viewer
  13. Ambient LED
  14. V-Tuner
  15. 3D OSD
  16. Smart Keyboard
  17. Smart Backup
  18. BIOS Setup
  19. Color Temperature
  20. Platform Power Management
  21. Game Boost
• Software in Bundle
  1. cFosSpeed
  2. Norton® Internet Security (OEM version)
  3. Intel® Optane™ Memory Ready
• Sistema Operativo
  1. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
  2. Windows® 10 64-bit (for 7th Generation Intel® Processors)
  3. Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
• Caratteristiche Fisiche
  1. Micro ATX Form Factor; 22.6cm x 19.3cm
