DESCRIZIONE

• CPU
  Intel® Socket 1151 for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.


• Chipset
  Intel® B250
• Memoria
  4 x DIMM, Max. 64GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory *
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)

  * Due to Intel® chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th Generation Intel® processors. Higher memory modules will run at the maximum transfer rate of DDR4 2400MHz.
  ** Due to Intel® chipset limitation, DDR4 2133MHz and higher memory modules on 6th Generation Intel® processors will run at the maximum transfer rate of DDR4 2133MHz.
• Grafica
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DVI-D/RGB ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 1024 MB
• Supporto Multi-GPU
  Supports AMD CrossFireX™ Technology
• Slot di Espansione
  1 x PCIe 3.0/2.0 x16 (x16 mode, gray)
  1 x PCIe 3.0/2.0 x16 (max at x4 mode, black) *¹
  2 x PCIe 3.0/2.0 x1
  2 x PCI
• Storage
  Intel® B250 Chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)*²
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
  6 x SATA 6Gb/s port(s)
  Intel® Optane™ Memory Ready *³
• LAN
  Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
  ASUS LAN Guard
• Audio
  Realtek® ALC887 8-Channel High Definition Audio CODEC *⁴
  Audio Feature :
  - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
  - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
• Porte USB
  Intel® B250 Chipset :
  1 x USB 3.0 port(s) (1 at back panel, , Type-C, Reversible, Support 3A power output)
  Intel® B250 Chipset :
  4 x USB 3.0/2.0 port(s) (2 at back panel, blue, Type-A, 2 at mid-board)
  Intel® B250 Chipset :
  6 x USB 2.0/1.1 port(s) (4 at back panel, black, Type-A, 2 at mid-board)
• Caratteristiche Speciali
  ASUS 5X Protection III :
  - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
  - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
  - ASUS Overvoltage Protection: World-class circuit-protecting power design
  - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
  - ASUS DIGI+ VRM: 6 Phase digital power design
  ASUS EPU :
  - EPU
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  - Low EMI Solution
  - ESD Guards
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  ASUS Quiet Thermal Solution :
  - Stylish Fanless Design Heat-sink solution
  - ASUS Fan Xpert 2+
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS MyLogo 2
  - ASUS UEFI BIOS EZ Mode
  ASUS Q-Design :
  - ASUS Q-Slot
  - ASUS Q-DIMM
  Digi+VRM
  M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)
• Porte I/O Posteriori
  1 x PS/2 keyboard/mouse combo port(s)
  1 x DVI-D
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  1 x USB 5Gb/s port(s) Type-C ( support 3A power output )
  2 x USB 3.0 (blue)
  4 x USB 2.0
  3 x Audio jack(s)
• I/O Interne
  1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  2 x M.2 Socket 3
  1 x COM port(s) connector(s)
  6 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  2 x Chassis Fan connector(s) (2 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
• Accessori
  User's manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  2 x M.2 screws
  1 x Supporting DVD
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information
• Gestibilità
  WfM 2.0, DMI 3.0, WOL by PME, PXE
• Disco di Supporto
  Drivers
  ASUS Utilities
  EZ Update
  Anti-virus software (OEM version)
• Sistema Operativo
  Windows® 10 64-bit
  Windows® 8.1 64-bit *⁵
  Windows® 7 32-bit *⁵
  Windows® 7 64-bit *⁵
• Dimensioni Scheda
  ATX Form Factor
  12 inch x 8.6 inch ( 30.5 cm x 21.8 cm )
