General information
Type    CPU / Microprocessor
Market segment    Desktop
Family
Intel Core i5
Model number
i5-4670K
CPU part numbers

    CM8064601464506 is an OEM/tray microprocessor
    BX80646I54670K is a boxed processor with fan and heatsink (English version)
    BXC80646I54670K is a boxed processor with fan and heatsink (Chinese version)
    BXF80646I54670K is a boxed processor without fan and heatsink

Frequency       3400 MHz
Turbo frequency    3600 MHz (4 cores)
3700 MHz (3 cores)
3800 MHz (1 or 2 cores)
Bus speed       5 GT/s DMI
Clock multiplier       34
Package    1150-land Flip-Chip Land Grid Array
Socket    Socket 1150 / H3 / LGA1150
Size    1.48" x 1.48" / 3.75cm x 3.75cm
Introduction date    June 2, 2013 (launch)
June 4, 2013 (announcement)
End-of-Life date    Last order date is December 24, 2015
Last shipment date is June 3, 2016

S-spec numbers
Part number     ES/QS processors     Production processors
      QE6V     QEH9     SR14A
BX80646I54670K              +
BXC80646I54670K              +
BXF80646I54670K              +
CM8064601464506    +         +
Unknown         +
Architecture / Microarchitecture
Microarchitecture    Haswell
Processor core       Haswell
Core stepping       C0 (QE6V, SR14A)
CPUID    306C3 (QE6V)
Manufacturing process    0.022 micron
Data width    64 bit
The number of CPU cores    4
The number of threads    4
Floating Point Unit    Integrated
Level 1 cache size       4 x 32 KB 8-way set associative instruction caches
4 x 32 KB 8-way set associative data caches
Level 2 cache size       4 x 256 KB 8-way set associative caches
Level 3 cache size    6 MB 12-way set associative shared cache
Physical memory    32 GB
Multiprocessing    Uniprocessor
Features

    MMX instructions
    SSE / Streaming SIMD Extensions
    SSE2 / Streaming SIMD Extensions 2
    SSE3 / Streaming SIMD Extensions 3
    SSSE3 / Supplemental Streaming SIMD Extensions 3
    SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4
    AES / Advanced Encryption Standard instructions
    AVX / Advanced Vector Extensions
    AVX2 / Advanced Vector Extensions 2.0
    BMI / BMI1 + BMI2 / Bit Manipulation instructions
    F16C / 16-bit Floating-Point conversion instructions
    FMA3 / 3-operand Fused Multiply-Add instructions
    EM64T / Extended Memory 64 technology / Intel 64
    NX / XD / Execute disable bit
    TBT 2.0 / Turbo Boost technology 2.0
    VT-x / Virtualization technology

Low power features    Enhanced SpeedStep technology
Integrated peripherals / components
Integrated graphics    GPU Type: HD 4600
Graphics tier: GT2
Microarchitecture: Gen 7.5
Execution units: 20
Base frequency (MHz): 350
Maximum frequency (MHz): 1200
The number of supported displays: 3
Memory controller    The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1333, DDR3-1600
Maximum memory bandwidth (GB/s): 25.6
Other peripherals

    Direct Media Interface 2.0
    PCI Express 3.0 interface

Electrical / Thermal parameters
Maximum operating temperature       72.72°C
Thermal Design Power       84 Watt
Notes on Intel Core i5-4670K

    The processor has unlocked clock multiplier
    The processor has the following security, data protection and/or software features: Intel Secure Key, Identity Protection technology, OS Guard and Anti-Theft technology.
    The CPU is compatible with DirectX 11.2, OpenGL 4.3 and OpenCL 1.2 APIs.
    The graphics unit has the following software features enabled: Intel Wireless Display, Quick Sync Video, Clear Video HD technology, InTru 3D technology and Insider.
