| Processore |
- Support for 7th and 6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package
- La Cache L3 varia da CPU a CPU
- Please refer "CPU Support List" for more information
|
| Chipset |
- Intel® Z270 Express Chipset
|
| Memoria |
- 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
- * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
- Architettura di memoria a doppio canale
- Support for DDR4 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz memory modul
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Supporta le memorie dotate di Profilo XMP
*Please refer "Memory Support List" for more information
|
| Grafica integrata |
Integrated Graphics Processor - Intel® HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
- * Support for DisplayPort 1.2 version.
Maximum shared memory of 1 GB
Integrated Graphics Processor+Intel® Thunderbolt™ 3 Controller:
- *Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™ devices that can be used is dependent on the number of the PCI Express devices being installed. (Refer to Chapter 1-7, "Back Panel Connectors," for more information.)
- 1 x Intel® Thunderbolt™ 3 connector, supporting DisplayPort and Thunderbolt™ video outputs and a maximum resolution of 4096x2304@60 Hz
|
| Audio |
- Realtek® ALC1220 codec
- Audio ad alta definizione
- Audio a 2/4/5.1/7.1 canali
- Supporta uscite S/PDIF
|
| LAN |
- 2 x Intel® GbE LAN chips (10/100/1000 Mbit)
|
| Slot di Espansione |
- 1 Slot PCI Express 16X,
operante a 16X
*Per migliori Performance, se solo una Scheda Video PCI è installata,
assicurati che questi sia inserita in uno Slot PCI Express 16X.
- 1 Slot PCI Express 16X, operante a 8X
* Lo Slot PCI Express 8X condivide la banda con lo slot PCI Express 16X, ragion per cui quando lo slot da 8X è in uso quello da 16X lavora a 8X.
- 1 x Slot PCI Express x16, funzionante a x4 (PCIEX4)
- *The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. When the PCIEX1_2 slot or the PCIEX1_3 slot is populated, the PCIEX4 slot will operate at up to x1 mode.
- 3 x Slot PCI Express
- (All of the PCI Express slots conform to PCI Express 3.0 standard.)
|
| Tecnologia Multi GPU |
- Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies
- Support for AMD Quad-GPU CrossFireX™ and 3-Way/2-Way AMD CrossFire™ technologies
|
| Interfaccia di storage |
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
- 6 x SATA 6Gb/s connectors
- * Refer to "1-9 Internal Connectors," for the installation notices for the U.2, M.2, and SATA connectors.
- 1 x U.2 connector
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
|
| USB |
Chipset:
- 7 x USB 3.1 Gen 1 ports (3 ports on the back panel, 4 ports available through the internal USB headers)
- 7 x USB 2.0/1.1 ports (2 ports on the back panel, 1 port onboard, 4 ports available through the internal USB headers)
Chipset+Intel® Thunderbolt™ 3 Controller:
- 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
|
| Connettori Interni I/O |
- 1 Connettore di Alimentazione ATX ad 8-pin
- 1 Connettore per Ventola della CPU
- 1 Connettore per Pannello Frontale
- 1 Connettore di Alimentazione ATX a 24-pin
- 1 Connettore per uscite Audio Frontali
- 1 x Clear CMOS jumper
- 1 x S/PDIF Out header
- 6 x SATA 6Gb/s connectors
- 1 x Trusted Platform Module (TPM) header
- 1 x M.2 Socket 3 connector
- 2 x SATA DOM power connectors
- 3 x system fan headers
- 2 x Connettori USB 2.0/1.1
- 1 x USB 2.0/1.1 port
- 2 x USB 3.1 Gen 1 headers
- 1 x Thunderbolt™ add-in card connector
- 1 x U.2 connector
- 1 x Pulsante di accensione
- 1 x Pulsante di Reset
- 1 x system fan/water cooling pump header
- Punti di lettura delle Tensioni
- 1 x Clear CMOS button
- 1 x ECO button
- 1 x OC button
- 1 x water cooling CPU fan header
- 2 x temperature sensor headers
- 2 x serial port headers
- 1 x DualBIOS™ switch
- 1 x power information detection header (PMBUS)
|
| Pannello Posteriore I/O |
- 3 x USB 3.1 Gen 1 ports
- 1 x optical S/PDIF Out connector
- 2 x USB 2.0/1.1 ports
- 1 Porta HDMI
- 1 Connessione per Mouse e Tastiera PS/2
- 1 x DisplayPort
- 1 x Thunderbolt™ 3 connector (USB Type-C™ port, with USB 3.1 Gen 2 support)
- 1 x USB 3.1 Gen 2 Type-A port (red)
- 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
- 2 x RJ-45 ports
|
| I/O Controller |
|
| Monitoraggio H/W |
- Fan fail warning
- Overheating warning
- Fan speed detection
- Temperature detection
- Voltage detection
- Fan speed control
- * Whether the fan speed control function is supported will depend on the cooler you install.
|
| BIOS |
- Support for DualBIOS™
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 2 x 128 Mbit flash
|
| Altre Caratteristiche |
- Supporta il Q-Flash
- Supporta i dischi con capacità superiore ai 3TB
- Support for Xpress Install
- Support for APP Center
- * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
- @ BIOS ™
- Auto Green
- Supporto alla tecnologia ON/OFF Charge
- Support for Cloud Station
- EasyTune
- USB Blocker
- Smart TimeLock
- Fast Boot
- System Information Viewer
- V-Tuner
- 3D OSD
- Smart Keyboard
- Smart Backup
- BIOS Setup
- Color Temperature
- Platform Power Management
- Game Boost
- Ambient LED
- Easy RAID
|
| Software in Bundle |
- Norton® Internet Security (OEM version)
- Intel® Optane™ Memory Ready
- cFosSpeed
|
| Sistema Operativo |
- Windows® 10 64-bit (for 7th Generation Intel® Processors)
- Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
- * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
|
| Caratteristiche Fisiche |
- ATX Form Factor; 30.5cm x 24.4cm
|
