CPU Processore Desktop Intel Core i7-7700 BX80677I77700
CPU Processore Desktop Intel Core i7-7700 3,6 GHz Kaby Lake Socket 1151 - boxed
ID: 1963
MODELLO: BX80677I77700
NOME COMMERCIALE: Intel Core i7-7700
EAN: 5032037092623
CONDIZIONE: Nuovo
RECESSO: Fino a 14 giorni (politica di recesso )
Visualizzazioni 1362
Recensioni 0
Rating 0 di 5
SOSPESO
€
357.64
Costo spedizione: € 9.00
Inserisci nel carrello
TAG
Tecnologia
Intel
Socket
1151
Famiglia
Intel Core i7
N. Core
4 Core
Threads
8
Frequenza Base
Da 3.0GHz a 4.0GHz
Frequenza Turbo
Da 4.0GHz a 5.0GHz
Cache
L3 - 8MB
TDP
Da 26W Fino a 65W
Grafica Integrata
Si
Dissipatore
Si
Set di Istruzioni
64 bit
Confezione
Box
DESCRIZIONE
Specifications
|
-
Essentials |
||
| Processor Number | i7-7700 | |
| Status | Launched | |
| Launch Date | Q1'17 | |
| Lithography | 14 nm | |
|
-
Performance |
||
| # of Cores | 4 | |
| # of Threads | 8 | |
| Processor Base Frequency | 3.60 GHz | |
| Max Turbo Frequency | 4.20 GHz | |
| Cache | 8 MB SmartCache | |
| Bus Speed | 8 GT/s DMI3 | |
| # of QPI Links | 0 | |
| TDP | 65 W | |
|
-
Supplemental Information |
||
| Embedded Options Available
|
Yes | |
| Conflict Free | Yes | |
| Datasheet | ||
|
-
Memory Specifications |
||
| Max Memory Size (dependent on memory type) | 64 GB | |
| Memory Types | DDR4-2133/2400, DDR3L-1333/1600 @ 1.35V | |
| Max # of Memory Channels | 2 | |
| ECC Memory Supported ‡
|
No | |
|
-
Graphics Specifications |
||
| Processor Graphics ‡ | Intel® HD Graphics 630 | |
| Graphics Base Frequency | 350.00 MHz | |
| Graphics Max Dynamic Frequency | 1.15 GHz | |
| Graphics Video Max Memory | 64 GB | |
| 4K Support | Yes, at 60Hz | |
| Max Resolution (HDMI 1.4)‡ | 4096x2304@24Hz | |
| Max Resolution (DP)‡ | 4096x2304@60Hz | |
| Max Resolution (eDP - Integrated Flat Panel)‡ | 4096x2304@60Hz | |
| DirectX* Support | 12 | |
| OpenGL* Support | 4.4 | |
| Intel® Quick Sync Video
|
Yes | |
| Intel® InTru™ 3D Technology | Yes | |
| Intel® Clear Video HD Technology | Yes | |
| Intel® Clear Video Technology | Yes | |
| # of Displays Supported ‡ | 3 | |
| Device ID | 0x5912 | |
|
-
Expansion Options |
||
| Scalability | 1S Only | |
| PCI Express Revision | 3.0 | |
| PCI Express Configurations ‡ | Up to 1x16, 2x8, 1x8+2x4 | |
| Max # of PCI Express Lanes | 16 | |
|
-
Package Specifications |
||
| Sockets Supported | FCLGA1151 | |
| Max CPU Configuration | 1 | |
| Thermal Solution Specification | PCG 2015C (65W) | |
| TJUNCTION | 100°C | |
| Package Size | 37.5mm x 37.5mm | |
| Low Halogen Options Available | See MDDS | |
|
-
Advanced Technologies |
||
| Intel® Turbo Boost Technology ‡ | 2.0 | |
| Intel® vPro Technology ‡
|
Yes | |
| Intel® Hyper-Threading Technology ‡
|
Yes | |
| Intel® Virtualization Technology (VT-x) ‡ | Yes | |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡
|
Yes | |
| Intel® VT-x with Extended Page Tables (EPT) ‡
|
Yes | |
| Intel® TSX-NI | Yes | |
| Intel® 64 ‡
|
Yes | |
| Instruction Set | 64-bit | |
| Instruction Set Extensions | SSE4.1/4.2, AVX 2.0 | |
| Idle States | Yes | |
| Enhanced Intel SpeedStep® Technology
|
Yes | |
| Thermal Monitoring Technologies | Yes | |
| Intel® Identity Protection Technology ‡ | Yes | |
| Intel® Stable Image Platform Program (SIPP) | Yes | |
|
-
Intel® Data Protection Technology |
||
| Intel® AES New Instructions
|
Yes | |
| Secure Key | Yes | |
| Intel® Software Guard Extensions (Intel® SGX) | Yes | |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes | |
|
-
Intel® Platform Protection Technology |
||
| OS Guard | Yes | |
| Trusted Execution Technology ‡
|
Yes | |
| Execute Disable Bit ‡ | Yes | |
| Intel® Device Protection Technology with Boot Guard | Yes | |
