DESCRIZIONE

• CPU
  Intel® Socket 1151 for 7^th/6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
• Chipset
  Intel® Z270
• Memoria
  4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered, Register Memory
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• Grafica
  Integrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : HDMI/DisplayPort 1.2 ports
  - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
  - Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
  Supports up to 3 displays simultaneously
  DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays
• Supporto Multi-GPU
  Supports NVIDIA® 2-Way SLI™ Technology
  Supports AMD 2-Way CrossFireX Technology
• Slot di Espansione
  2 x PCIe 3.0/2.0 x16 (x16 or dual x8)
  2 x PCIe 3.0/2.0 x1
• Storage
  Intel® Z270 Chipset :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*¹
  1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*²
  6 x SATA 6Gb/s port(s)
  Intel® Optane™ Memory Ready *³
• LAN
  Intel® I219V, Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY)
  Anti-surge LANGuard
  ROG GameFirst Technology
• Wireless Data Network
  Wi-Fi 802.11 a/b/g/n/ac
  Supports dual band frequency 2.4/5 GHz
  Supports MU-MIMO
• Bluetooth
  Bluetooth V4.1
• Audio
  ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
  - Dual Headphone Amplifiers
  - Impedance sense for front and rear headphone outputs
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  - Supports up to 32-Bit/192kHz playback *⁴
  Audio Feature :
  - SupremeFX Shielding™ Technology
  - Optical S/PDIF out port(s) at back panel
  - Sonic Radar III
  - Sonic Studio III
• Porte USB
  Intel® Z270 Chipset :
  6 x USB 3.0 port(s) (4 at back panel, blue, 2 at mid-board)
  Intel® Z270 Chipset :
  6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)
  ASMedia® USB 3.1 controller :
  1 x USB 3.1 front panel connector port(s)
  ASMedia® USB 3.1 controller :
  2 x USB 3.1 port(s) (2 at back panel, black+red, Type-A + Type-C)
• Caratteristiche Overclock
  ROG RAMCache II
  ROG CPU-Z
  ROG CloneDrive
  Overwolf
  GameFirst IV
• Caratteristiche Speciali
  5-Way Optimization by Dual Intelligent Processors 5
  - Whole system optimization with a single click! 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ Power Control, Fan Xpert 4, and Turbo App together, providing better CPU performance, efficient power saving, precise digital power control, whole system cooling and even tailor your own app usages.
  TPU
  - Auto Tuning, TurboV, GPU Boost
  - Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors
  selection for optimized system cooling control
  Gamer's Guardian:
  - ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports
  - DRAM Overcurrent Protection
  - Stainless Steel Back I/O
  - Highly Durable Components
  - DIGI+ VRM
  - SafeSlot
  ASUS EPU :
  - EPU
  AURA :
  - Aura Lighting Control
  - Aura RGB Strip Headers
  - Aura Lighting Effects Synchronization with compatible ASUS ROG devices
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
  Gaming Aesthetics :
  - 3D printing friendly
  Digi+VRM
• Porte I/O Posteriori
  1 x PS/2 keyboard/mouse combo port(s)
  1 x DisplayPort
  1 x HDMI
  1 x LAN (RJ45) port(s)
  2 x USB 3.1 Type-A + Type-C
  2 x USB 2.0
  4 x USB 3.0
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.1)
• I/O Interne
  1 x AAFP connector
  2 x Aura RGB Strip Headers
  1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  1 x TPM connector(s)
  6 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x CPU OPT Fan connector(s) (1 x 4 -pin)
  2 x Chassis Fan connector(s) (2 x 4 -pin)
  1 x W_PUMP+ connector (1 x 4 -pin)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Thermal sensor connector(s)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
  1 x USB 3.1 front panel connector
  1 x CPU_OV jumper
• Accessori
  User's manual
  I/O Shield
  4 x SATA 6Gb/s cable(s)
  1 x CPU installation tool
  1 x Supporting DVD
  1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
  1 x SLI HB BRIDGE(2-WAY-S)
  1 x ROG Strix stickers
  1 x M.2 screw kit (long screw and mount)
  1 x M.2 screw kit (short screw and mount)
  1 x 10 in 1 Cable Label (s)
  1 x Extension Cable for RGB strips (40 cm)
  1 x 3D printing mount package
  1 x ROG coasters
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Gestibilità
  WfM2.0, DMI3.0, WOL by PME, PXE
• Disco di Supporto
  Drivers
  ROG GameFirst IV*
  ROG RAMCache II
  ROG Clone Drive
  Aura
  ROG CPU-Z
  Anti-virus software (OEM version)
  ASUS WebStorage
  ASUS Utilities

  *ROG GameFirst IV is only available for Windows 10/8.1 64-bit
• Sistema Operativo
  Windows® 10 64-bit
  Windows® 8.1 64-bit *⁵
  Windows® 7 32-bit *⁵
  Windows® 7 64-bit *⁵
• Dimensioni Scheda
  mATX Form Factor
  9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
• Note
  *1 The M.2_1 socket shares bandwidth with SATA_1 port when using M.2 SATA mode device. Adjust BIOS settings to use SATA device.
  *2 Located at back of the motherboard
  *3 Intel® Optane Technology only supported when using 7th Generation Intel® Processors. Before using Intel® Optane memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website.
  *4 Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio
  *5 Windows® 8.1 64-bit and Windows® 7 32/64-bit are only supported when using 6th Generation Intel® Processors.
