DESCRIZIONE

• CPU
  AMD AM3+ FX™/Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors
  Supports AM3+ 32 nm CPU
  Supports CPU up to 8 cores
  Supports CPU up to 140 W
  AMD Cool 'n' Quiet™ Technology
• Chipset
  AMD 990X/SB950
• Memory
  4 x DIMM, Max. 32GB, DDR3 2133(O.C.)/1866/1600/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows® OS when you want to install 4GB or more memory on the motherboard.
  * Due to CPU spec., AMD 100 series CPUs support up to DDR3 1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz.
• System Bus
  Up to 5.2 GT/s HyperTransport™ 3.0
• Multi-GPU Support
  Supports NVIDIA® Quad-GPU SLI™ Technology
  Supports AMD Quad-GPU CrossFireX™ Technology
• Expansion Slots
  2 x PCIe 2.0 x16 (x16 or dual x8)
  1 x PCIe 2.0 x16 (x4 mode, black)
  2 x PCIe 2.0 x1
  1 x PCI
• Storage
  AMD SB950 controller :
  6 x SATA 6Gb/s port(s), gray
  Support Raid 0, 1, 5, 10
  ASMedia® PCIe SATA controller :
  2 x eSATA 6Gb/s port(s), red
• LAN
  Realtek® 8111F, 1 x Gigabit LAN Controller(s)
• Audio
  Realtek® ALC892 8-Channel High Definition Audio CODEC
  - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  Audio Feature :
  - Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound
  - Blu-ray audio layer Content Protection
  - DTS Ultra PC II
  - DTS Connect
  - ASUS Noise Filter
  - Optical S/PDIF out port(s) at back panel
• USB Ports
  ASMedia® USB 3.0 controller :
  4 x USB 3.0/2.0 port(s) (2 at back panel, blue, 2 at mid-board)
  AMD SB950 controller :
  14 x USB 2.0/1.1 port(s) (8 at back panel, black+red, 6 at mid-board)
• ROG Exclusive Features
  Overclocking Protection :
  - ASUS C.P.R.(CPU Parameter Recall)
• Special Features
  ASUS Dual Intelligent Processors 3 with New DIGI+ Power Control :

  SMART DIGI+ :
  - Smart DIGI+ Key- Quickly delivers optimized VRM frequency, voltage and current for superior CPU/DRAM overclocking performance with one click.
  ASUS TPU :
  - Auto Tuning
  - TurboV
  - TPU switch
  ASUS EPU :
  - EPU
  - EPU switch
  ASUS Digital Power Design :
  - Industry leading Digital 6 +2 Phase Power Design
  - Industry leading Digital 2 Phase DRAM Power Design
  - CPU Power Utility
  - DRAM Power Utility
  ASUS Exclusive Features :
  - Remote GO!
  - USB BIOS Flashback
  - MemOK!
  - AI Suite II
  - Ai Charger+
  - Front Panel USB 3.0 Support
  - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
  - Network iControl
  - USB 3.0 Boost
  ASUS Quiet Thermal Solution :
  - Stylish Fanless Design Heat-pipe solution
  - ASUS Fan Xpert
  ASUS EZ DIY :
  - DirectKey
  - Precision Tweaker 2
  - ASUS O.C. Profile
  - ASUS EZ Flash 2
  - ASUS MyLogo 2
  - Multi-language BIOS
  ASUS Q-Design :
  - ASUS Q-Shield
  - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  - ASUS Q-Slot
  - ASUS Q-DIMM
  - ASUS Q-Connector
• Operating System Support
  Windows® 8.1
  Windows® 8
  Windows® 7
  Windows® Vista
  Windows® XP
• Back I/O Ports
  1 x PS/2 keyboard/mouse combo port(s)
  2 x eSATA 6Gb/s
  1 x LAN (RJ45) port(s)
  2 x USB 3.0
  8 x USB 2.0 (one port can be switched to USB BIOS Flashback)
  1 x Optical S/PDIF out
  6 x Audio jack(s)
• Internal I/O Ports
  1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)
  3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
  1 x TPM connector(s)
  1 x COM port(s) connector(s)
  6 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x CPU OPT Fan connector(s) (1 x 4 -pin)
  3 x Chassis Fan connector(s) (3 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s) (Q-Connector)
  1 x DirectKey Button(s)
  1 x DRCT header(s)
  1 x MemOK! button(s)
  1 x TPU switch(es)
  1 x EPU switch(es)
  1 x Clear CMOS jumper(s)
  1 x USB BIOS Flashback button(s)
• Accessories
  User's manual
  I/O Shield
  4 x SATA 6Gb/s cable(s)
  1 x SLI bridge(s)
  1 x Q-connector(s) (2 in 1)
• BIOS
  64 Mb Flash ROM, UEFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, F12 PrintScreen, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability
  WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
• Support Disc
  Drivers
  ASUS Utilities
  ASUS Update
  Anti-virus software (OEM version)
• Form Factor
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
