Scheda Madre Gigabyte H110M-S2H GA-H110M-S2H

Scheda Madre Gigabyte 1151 Socket 1151 Chipset Intel H110 DDR4 mATX

ID: 1757
MODELLO: GA-H110M-S2H
NOME COMMERCIALE: Scheda Madre Gigabyte H110M-S2H
EAN: 4719331837310
CONDIZIONE: Nuovo
RECESSO: Fino a 14 giorni (politica di recesso )
GARANZIA: ITALIA Fino a 24 mesi (condizioni di garanzia )
Visualizzazioni 539
Recensioni 0
Rating 0 di 5
SOSPESO
Scheda Madre Gigabyte H110M-S2H GA-H110M-S2H
68.40
Costo spedizione: € 9.00
Inserisci nel carrello
Quantità

TAG

Tecnologia
Intel
Socket
Intel 1151
Chipset
Intel H110
Formato
Micro ATX
Supporto RAM
DDR4
SATA3
4-porte
USB 2.0
+ 6-porte
USB 3.0
4-porte
Output Video
VGA-DVI-HDMI

DESCRIZIONE

Processore
  1. La Cache L3 varia da CPU a CPU
  2. Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
(Please refer "CPU Support List" for more information.)
Chipset
  • Intel® H110 Express Chipset
Memoria
  1. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
  2. 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
  3. Architettura di memoria a doppio canale
  4. Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  5. Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules
  6. Support for DDR4 2133 MHz memory modules
((Per maggiori informazioni fare riferimento alla Lista di memorie compatibili))
Grafica integrata Integrated Graphics Processor - Intel® HD Graphics support:
  1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
  2. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
    * The DVI-D port does not support D-Sub connection by adapter.
  3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
    * Support for HDMI 1.4 version.
Support for up to 2 displays at the same time
Maximum shared memory of 512 MB
Audio
  1. Audio ad alta definizione
  2. Supporta uscite S/PDIF
  3. Audio a 2/4/5.1/7.1 canali
    *To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
  4. Realtek® ALC887 codec
LAN
  • Realtek® GbE LAN chip (10/100/1000 Mbit)
Slot di Espansione
  1. (The PCI Express x16 slot conforms to PCI Express 3.0 standard.)
  2. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
  3. 2 x PCI Express x1 slots
  4. (All of the PCI Express x1 slots conform to PCI Express 2.0 standard.)
Interfaccia di storage Chipset:
  • 4 x SATA 6Gb/s connectors
USB Chipset:
  1. 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
  2. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Connettori Interni I/O
  1. 1 Connettore di Alimentazione ATX ad 8-pin
  2. 1 Connettore per Ventola della CPU
  3. 1 Connettore per Pannello Frontale
  4. 1 Connettore di Alimentazione ATX a 24-pin
  5. 1 Connettore per uscite Audio Frontali
  6. 4 Connessioni SATA 6Gb/s
  7. 1 Connettore per porte USB 3.0/2.0
  8. 1 x Connettore per System Fan
  9. 2 x Connettori USB 2.0/1.1
  10. 1 Porta seriale
  11. 1 x Clear CMOS jumper
  12. 1 x S/PDIF Out header
  13. 1 x Trusted Platform Module (TPM) header
Pannello Posteriore I/O
  1. 4 x USB 2.0/1.1 ports
  2. 2 x USB 3.0/2.0 ports
  3. 1 Porta HDMI
  4. 1 x PS/2 mouse port
  5. 1 x PS/2 keyboard port
  6. 1 Porta RJ-45
  7. 1 x Porta D-Sub
  8. 1 x Porta DVI-D
  9. 3 x audio jacks (Line In, Line Out, Mic In)
I/O Controller
  • iTE® I/O Controller Chip
Monitoraggio H/W
  1. Rilevamento della velocità di rotazione della ventola della CPU e del Sistema
  2. CPU/System fan speed control
  3. Allarme per il malfunzionamento della ventole della CPU e del sistema
  4. CPU/System overheating warning
  5. Rilevamento dei voltaggi del sistema
  6. *Whether the fan speed control function is supported will depend on the cooler you install.
  7. Rilevamento delle temperature di CPU e di Sistema
BIOS
  1. 1 x 64 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Altre Caratteristiche
  1. Support for Smart Switch
  2. Support for Xpress Install
  3. Supporta il Q-Flash
  4. Support for APP Center
    * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
  5. Auto Green
  6. Support for Cloud Station
  7. @ BIOS ™
  8. EasyTune
  9. USB Blocker
  10. Smart TimeLock
  11. Fast Boot
  12. System Information Viewer
  13. 3D OSD
  14. Smart Keyboard
  15. Smart Backup
Software in Bundle
  1. cFosSpeed
  2. Norton® Internet Security (OEM version)
Sistema Operativo
  1. Support for Windows 10/8.1 64-bit
  2. Support for Windows 7 32-bit/64-bit
  3. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
Caratteristiche Fisiche
  • Micro ATX Form Factor; 22.6cm x 17.4cm
Note
  1. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
  2. A causa delle diverse condizioni di supporto per Linux fornito da fornitori di chipset, scaricare il driver Linux dal sito web fornitori di chipset.
