DESCRIZIONE

• CPU
  Intel® Socket 2011-v3 Core™ i7 Processors
  Supports Intel® 22 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.


• Chipset
  Intel® X99
• Memoria
  8 x DIMM, Max. 64GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory
• Supporto Multi-GPU
  Supports NVIDIA® Quad-GPU SLI™ Technology
  Supports NVIDIA® 3-Way SLI™ Technology
  Supports AMD Quad-GPU CrossFireX™ Technology
  Supports AMD 3-Way CrossFireX™ Technology
• Slot di Espansione
  40-Lane CPU-
  3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8) *¹
  28-Lane CPU-
  3 x PCIe 3.0/2.0 x16 ( x16, x16/x8, x16/x8/x4) *¹
  1 x PCIe 2.0 x4 (x2 mode)
  1 x PCIe 2.0 x1
• Storage
  New Intel® Core™ i7 Processors :
  1 x M.2 Socket 3, graywith M Key, type 2242/2260/2280/22110 storage devices support (Support PCIE SSD only)
  Intel® X99 chipset :
  1 x SATA Express portcompatible with 2 x SATA 6.0 Gb/s ports
  8 x SATA 6Gb/s port(s),
  Support Raid 0, 1, 5, 10
  Supports Intel® Smart Response Technology, Intel® Rapid Recovery Technology*²
• LAN
  Intel® I218V, 1 x Gigabit LAN Controller(s)
  Realtek® 8111GR, 1 x Gigabit LAN
  Gigabit Intel® LAN Connection- 802.3az Energy Efficient Ethernet (EEE) appliance
  ASUS Turbo LAN Utility
• Audio
  Realtek® ALC1150 8-Channel High Definition Audio CODEC
  Audio Feature :
  - Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound
  - Optical S/PDIF out port(s) at back panel
  - BD Audio Layer Content Protection
  - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
  - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  - Audio amplifier: Provides the highest-quality sound for headphone and speakers
  - Unique de-pop circuit: Reduces start-up popping noise to audio outputs
  - Top notch audio sensation delivers according to the audio configuration
  - Absolute Pitch 192khz/24bit true BD lossless sound
  Separate layer for left and right track, ensuring both sound deliver equal quality
• Porte USB
  Intel® X99 chipset :
  8 x USB 3.0 port(s) (4 at back panel, , 4 at mid-board)
  Intel® X99 chipset :
  8 x USB 2.0/1.1 port(s) (4 at back panel, , 4 at mid-board)
  ASMedia® USB 3.1 controller :
  2 x USB 3.1/3.0/2.0 port(s) (2 at back panel, +teal blue)
• Caratteristiche Speciali
  TUF Features:
  TUF ENGINE! Power Design :
  - 8 +2 Digital Phase Power Design
  - TUF Components (Choke, Cap. & MOSFET; certified by military-standard)
  - ASUS DIGI+ Power Control Utility
  Ultimate COOL! Thermal Solution :
  - TUF Thermal Armor
  - TUF Thermal Radar 2 with Thermistors
  - TUF ICe
  Safe & Stable! Guardian Angel :
  "We Got Your Back!" Shape Force
  - TUF Fortifier
  - Dust Defenders with connector covers and back I/O dust filter
  - TUF ESD Guards 2
• Operating System Support
  Windows® 8.1
  Windows® 8
  Windows® 7
• Porte I/O Posteriori
  2 x LAN (RJ45) port(s)
  2 x USB 3.1 (teal blue)
  4 x USB 3.0 (blue)
  4 x USB 2.0
  1 x Optical S/PDIF out
  5 x Audio jack(s)
  1 x USB BIOS Flashback Button(s)
• I/O Interne
  1 x AAFP connector
  2 x USB 3.0 connector(s) support(s) additional 4 USB 3.0 port(s) (19-pin)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x SATA Express connector: gray, compatible with 2 x SATA 6.0 Gb/s ports
  1 x TPM header
  1 x COM port(s) connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x CPU OPT Fan connector(s) (1 x 4 -pin)
  1 x CPU fan with PWM control
  4 x Chassis Fan connector(s) (4 x 4 -pin)
  5 x Assistant Fan connector(s) (5 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x Thunderbolt header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x System panel(s) (Q-Connector)
  1 x Chassis Intrusion connector(s)
  1 x MemOK! button(s)
  3 x Thermal sensor connector(s)
  1 x Clear CMOS jumper(s)
• Accessori
  User's manual
  Accessory Guide
  ASUS Q-Shield
  6 x SATA 6Gb/s cable(s)
  1 x ASUS 2-Way/3-Way SLI bridge
  1 x Supporting DVD
  1 x Q-connector(s) (2 in 1)
  1 x Assistant Fans(40mm)
  1 x TUF Certification card(s)
  1 x TUF 5 Year Warranty manual(s) (by region)
  1 x TUF Inside sticker(s)(white)
  1 x STAY COOL BE TUF sticker(s)(white)
  1 x Accessory Package(s):
  - 2 x PCIe x16 slot dust cover(s)
  - 4 x DRAM slot dust cover(s)
  - 1 x PCIe x1 slot dust cover(s)
  - 1 x PCIe x4 slot dust cover(s)
  - 3 x Thermistor cable(s)
  - 1 x connector dust cover collection(onboard USB 3.0, LAN)
  - 2 x On board USB 2.0 connector dust cover(s)
  - 11 x back I/O USB 2.0 connector dust cover(s)
  - 9 x On board SATA connector dust cover(s)
  - 1 x SATA Express conector dust cover(s)
  - 5 x Audio connector dust cover(s)
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI 5.0, Multi-language BIOS,
  ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log,
  F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Gestibilità
  WfM 2.0, DMI 2.7, WOL by PME, PXE
• Disco di Supporto
  Drivers
  Anti-virus software (OEM version)
  ASUS/TUF CPU-Z
  ASUS Utilities
• Dimensioni Scheda
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
• Note
  1* The PCIe x16_3 shares bandwidth with M.2 x4. When M.2 socket is occupied, the PCIe x16_3 slot will be disabled.
  2* Due to chipset behavior, The SATA6G_78, SATA6G_910 ports (black) do not support IRST including RAID configuration.
  3* These functions will work depending on the CPU installed.
