| Processore |
- Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
- La Cache L3 varia da CPU a CPU
(Please refer "CPU Support List" for more information.)
|
| Chipset |
- Intel® Z170 Express Chipset
|
| Memoria |
- 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
- * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
- Architettura di memoria a doppio canale
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Supporta le memorie dotate di Profilo XMP
- Support for DDR4 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz memory modules
((Per maggiori informazioni fare riferimento alla Lista di memorie compatibili))
|
| Grafica integrata |
Integrated Graphics Processor - Intel® HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4a version.
- * Support for DisplayPort 1.2 version.
- 1 x Mini-DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
Maximum shared memory of 512 MB
|
| Audio |
- Realtek® ALC892 codec
- Audio ad alta definizione
- Supporta uscite S/PDIF
- Audio a 2/4/5.1/7.1 canali
|
| LAN |
- Intel® GbE LAN chip (10/100/1000 Mbit)
|
| Slot di Espansione |
- 1 Slot PCI Express 16X,
operante a 16X
*Per migliori Performance, se solo una Scheda Video PCI è installata,
assicurati che questi sia inserita in uno Slot PCI Express 16X.
- 1 x Slot PCI Express x16, funzionante a x4 (PCIEX4)
- 1 x PCI Express x16 slot, running at x8 (PCIEX8)
- * The PCIEX4 slot shares bandwidth with the SATA3 0/1 connectors. When the PCIEX4 slot is installed with a x4 or above card, the SATA 3 0/1 connectors becomes unavailable.
- 3 x Slot PCI Express
- (All of the PCI Express slots conform to PCI Express 3.0 standard.)
- * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
|
| Tecnologia Multi GPU |
- Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies
- Support for AMD Quad-GPU CrossFireX™ and 2-Way AMD CrossFire™ technologies
|
| Interfaccia di storage |
Chipset:
- * Refer to "1-8 Internal Connectors," for the installation notices for the U.2, M.2, SATA Express, and SATA connectors.
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
- 2 x SATA Express connectors
- 6 x SATA 6Gb/s connectors
- 1 x U.2 connector
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
|
| USB |
Chipset:
- 6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Chipset + Intel® USB 3.1 Controller:
- 1 x USB Type-C™ port on the back panel, with USB 3.1 support
- 1 x USB 3.1 Type-A port (red) on the back panel
|
| Connettori Interni I/O |
- 1 x water cooling fan/pump header (CPU_OPT_PUMP)
- 2 x sistema di ventilazione
- 1 Connettore di Alimentazione ATX ad 8-pin
- 1 Connettore per Ventola della CPU
- 1 Connettore per Pannello Frontale
- 1 Connettore di Alimentazione ATX a 24-pin
- 1 Connettore per uscite Audio Frontali
- 1 Connettore per porte USB 3.0/2.0
- 2 x Connettori USB 2.0/1.1
- 1 x Clear CMOS jumper
- 1 x S/PDIF Out header
- 6 x SATA 6Gb/s connectors
- 1 x Trusted Platform Module (TPM) header
- 1 x M.2 Socket 3 connector
- 1 x Thunderbolt™ add-in card connector
- 2 x SATA Express connectors
- 1 x U.2 connector
- 1 x system fan/water cooling pump header (SYS_FAN2_PUMP)
|
| Pannello Posteriore I/O |
- 1 x Mini-DisplayPort In port
- 2 x USB 2.0/1.1 ports
- 1 x USB Type-C™ Port, with USB 3.1 support
- 1 x optical S/PDIF Out connector
- 1 Porta HDMI
- 4 x USB 3.0/2.0 ports
- 1 Connessione per Mouse e Tastiera PS/2
- 1 Porta RJ-45
- 1 x USB 3.1 Type-A port (red)
- 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
- 1 x Mini-DisplayPort
|
| I/O Controller |
|
| Monitoraggio H/W |
- Rilevamento dei voltaggi del sistema
- CPU/System/Chipset temperature detection
- CPU/System/Chipset overheating warning
- CPU/CPU OPT/System fan (pump) speed detection
- CPU/CPU OPT/System fan (pump) fail warning
- CPU/CPU OPT/System fan (pump) speed control
* Whether the fan speed control function is supported will depend on the fan (pump) you install.
|
| BIOS |
- Support for DualBIOS™
- Use of licensed AMI UEFI BIOS
- 2 x 128 Mbit flash
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
| Altre Caratteristiche |
- Support for Smart Switch
- Support for Xpress Install
- Supporta il Q-Flash
- Support for APP Center
* Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
- Supports EasyTune
- Auto Green
- Support for On/Off Charge
- Support for Cloud Station
- @ BIOS ™
- USB Blocker
- Smart TimeLock
- Fast Boot
- System Information Viewer
- V-Tuner
- 3D OSD
- Smart Keyboard
- Smart Backup
- Easy RAID
- BIOS Setup
- Color Temperature
- Platform Power Management
|
| Software in Bundle |
- Intel® Smart Response Technology
- cFosSpeed
- Norton® Internet Security (OEM version)
|
| Sistema Operativo |
- Support for Windows 10/8.1 64-bit
- Support for Windows 7 32-bit/64-bit
- * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
|
| Caratteristiche Fisiche |
- ATX Form Factor; 30.5cm x 24.4cm
|
| Note |
- Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
- A causa delle diverse condizioni di supporto per Linux fornito da fornitori di chipset, scaricare il driver Linux dal sito web fornitori di chipset.
|
